Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	5305024610		Side Panel Lh-wheat		Appelez-nous	-
1	5305024609		Side Panel Rh-wheat		Appelez-nous	-
2	316042101		Front - Oven		Appelez-nous	-
3	5308003107		Bumper, Cooktop (4)		Appelez-nous	-
4	3051632		Retainer, Insulation (2)		Appelez-nous	-
5	5303205540		Leg - Leveller (4)		Appelez-nous	-
6	5308015746		Rail-drawer Rh		Appelez-nous	-
7	3051654		Guide, Drawer Front (2)		Appelez-nous	-
8	3205257		Channel, Sub Top		Appelez-nous	-
9	5303293103		Oven Liner		Appelez-nous	-
10	5303271606		Cup-oven Light		Appelez-nous	-
11	316116400		Receptacle-light   (Replaces: 5308011085)			Immediately	$ 56.10
12	40A15		Light Bulb   (Replaces: 5303013071)			Immediately	$ 1.98
13	5303205904		Retainer-lens				$ 7.67
14	5304524341		Glass - Oven Light Lens   (Replaces: 08011086)			Immediately	$ 15.61
15	3051653		Spacer, Drawer Rail (2)		Appelez-nous	-
16	3205234		Grille, Broiler		Appelez-nous	-
17	5303292688		Pan-broiler		Appelez-nous	-
18	5303281625		Rack - Oven Regular		Appelez-nous	-
19	5304409888		Terminal Block   (Replaces: 5306563359)			Immediately	$ 26.69
20	5301145190		Strap, Ground		Appelez-nous	-
21	5303207391		Support-subtop		Appelez-nous	-
22	3206275		Panel, Bottom		Appelez-nous	-
23	3202082		Cover Seam		Appelez-nous	-
24	3203029		Insulation, Oven Wrap		Appelez-nous	-
25	3016334		Plug Button, Thermo Bulb Hole		Appelez-nous	-
26	3201632		Spacer, Oven (2)		Appelez-nous	-
27	3016281		Spring, Oven (2)		Appelez-nous	-
28	3051634		Channel, Air		Appelez-nous	-
29	5303051630		Insulation, Oven Back		Appelez-nous	-
30	3017481		Gusset-rear, Rh		Appelez-nous	-
31	5303051856		Cover, Wire		Appelez-nous	-
32	3205757		Back, Range		Appelez-nous	-
33	5303292687		Panel - Subtop		Appelez-nous	-
34	3017799		Switch-door		Appelez-nous	-
35	08007445		Push Rod		Appelez-nous	-
36	08007444		End-push Rod		Appelez-nous	-
37	3205683		Vent Tube		Appelez-nous	-
38	5308015743		Latch, Motor				$ 211.92
39	3051648		Latch-door		Appelez-nous	-
40	3051647		Housing-door Latch		Appelez-nous	-
41	5308012004		Axle				$ 8.29
42	3051649		Tie Bar		Appelez-nous	-
46	5303207389		Brkt-main Top		Appelez-nous	-
47	3019063		Retainer - Door (2)		Appelez-nous	-
48	3201631		Channel Assy, Hinge (2)				$ 58.22
49	3017556		Ballast		Appelez-nous	-
50	3051655		Tube, Oven Vent		Appelez-nous	-
51	3051656		Brkt-vent Tube		Appelez-nous	-
52	3051666		Gasket-oven Vent		Appelez-nous	-
53	5303293025		Protector-thermal		Appelez-nous	-
*71516	19100210049		Wiring Diagram-(not For Purchase)		Appelez-nous	-
18A	5305133401		Rack-oven Offset		Appelez-nous	-
30A	3017482		Gusset-rear, Lh		Appelez-nous	-
47A	3934063		Anti-tip Kit, (non-illustrated)		Appelez-nous	-
47B	5303284616		Clip - Capillary (2) (non-illustrated)				$ 9.86
6A	3051652		Rail, Drawer Lh		Appelez-nous	-
