02 - Cabinet And Air Flow Parts


03 - Interior And Ventilation Parts


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	4713-001013		Lamp			Immediately	$ 18.00
2	DE47-00006A		Holder-lamp				$ 17.58
3	DE59-50002A		Capacitor-motor			Immediately	$ 27.34
4	W10250842		Cover, Lamp		Appelez-nous	-
5	W10258160		Assy, Duct Upper		Appelez-nous	-
6	555555		Thermostat   (Replaces: DE47-20059A)				$ 151.94
7	W10181452		Motor, Fan Assy				$ 189.00
8	555555		Filter-charcoal   (Replaces: DE63-00367D)				$ 151.94
9	DE96-00218A		Cord, Power				$ 78.75
10	DE92-90508A		Holder Nut, Assy			Immediately	$ 17.58
11	W10199858		Case, Outer (bisque)		Appelez-nous	-
11	W10192096		Case, Outer (white)				$ 182.70
11	W10187744		Case, Outer (black)				$ 182.57
12	W10197773		Plate, Damper				$ 29.38
13	DE72-40022A		Damper, Assembly			Immediately	$ 12.07
14	555555		Plate-mounting   (Replaces: DE70-00378A)				$ 151.94
15	W10258198		Main Harness		Appelez-nous	-
16	DE92-90505E		Install, Hardware				$ 41.40
NI	W10188741		Template, Wall		Appelez-nous	-
NI	W10188240		Template, Upper				$ 5.01
