| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 4 | 5303305677 | Drier-filter (Replaces: 216634500) |
|
Immediately | $ 31.67 | ||||
| 5 | 216551600 | Wiring Harness |
|
$ 135.35 | |||||
| 22 | 216056400 | Clip, Spring Mtg |
|
- | |||||
| 27 | 218513300 | Grommet-compr Mtg,(4) |
|
$ 42.53 | |||||
| 28 | 5303212615 | Support, Compressor |
|
- | |||||
| 30 | 216649310 | Controller |
|
$ 18.90 | |||||
| 32 | 218740800 | Wire-bale |
|
$ 65.21 | |||||
| 42 | 216232700 | Washer-flat |
|
- | |||||
| 47 | 216629601 | Screw-hinge (Replaces: 216629600) |
|
$ 13.01 | |||||
| 85 | 216533600 | Wire-ground |
|
- | |||||
| 86 | 216036600 | Screw, Rwhd (gx, Ca), 8, 32 X 1/2 |
|
- | |||||
| 43A | 5303212614 | Clip Harness |
|
$ 2.88 | |||||
| F1 | 5303925320 | Condenser |
|
- | |||||
| F29 | 216755200 | Compressor,w/o Electricals |
|
- | |||||
| F55 | 5304464438 | Capacitor-run,220 Vac ,15 Microfarad (Replaces: 218909901) |
|
Immediately | $ 35.38 | ||||
| NI | 216478900 | Fastener, Energy Guide |
|
- | |||||
| NI | 5303298960 | Spacer-tube,.75`` |
|
- |
