Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	68434-1-AM		Divider, Mullion (alm)		Appelez-nous	-
1	65275-23		Screw		Appelez-nous	-
2	68830-1		Heater Wire		Appelez-nous	-
3	68903-1		Wire Harness		Appelez-nous	-
3	60140-1		Insulation		Appelez-nous	-
3	68577-1		Insulation		Appelez-nous	-
4	68530-2		Top, F.f. Compartment		Appelez-nous	-
5	60120-2		Deflector		Appelez-nous	-
6	WP68601-6		Control, Temperature   (Replaces: 68119-3)			Immediately	$ 233.80
6	29675-22		Ground Wire		Appelez-nous	-
6	406013-1		Screw		Appelez-nous	-
7	4008-12		Plastic Tube		Appelez-nous	-
8	60083-1		Cover, Temperature Control		Appelez-nous	-
8	405012-1		Screw		Appelez-nous	-
9	28013-2		Rivet, Air Tunnel		Appelez-nous	-
10	68600-1		Knob, Control		Appelez-nous	-
11	60147-1		Bracket, Control		Appelez-nous	-
12	WP210720		Rivet   (Replaces: 26397-2)				$ 12.14
13	68600-2		Knob, Frz.		Appelez-nous	-
13	W11233072		Screw   (Replaces: 405016-103)			Immediately	$ 12.62
14	420092-900		Washer, Spring		Appelez-nous	-
15	67558-6		Damper		Appelez-nous	-
16	67636-1		Crank, Frz. Control		Appelez-nous	-
17	67499-3		Rod, Freezer Control		Appelez-nous	-
18	WP59002061		Screw   (Replaces: 65275-13)				$ 6.98
18	420005-1		Washer, Control Rod		Appelez-nous	-
19	67493-1		Cover, Crank		Appelez-nous	-
20	60577-2		Socket, Light		Appelez-nous	-
21	40A15		Bulb, Light (40 Watt)   (Replaces: 31956)			Immediately	$ 1.98
22	60147-2		Bracket, Light Socket		Appelez-nous	-
23	WP210720		Rivet   (Replaces: 26397-2)				$ 12.14
24	29675-28		Ground Wire		Appelez-nous	-
25	W11384469		Switch, Light   (Replaces: 66987-1)			Immediately	$ 33.51
25	54653-32		Lead		Appelez-nous	-
26	54531-8		Grommet		Appelez-nous	-
27	65039-1		Cap, Drain Tube		Appelez-nous	-
28	66490-8		Pan, Meat		Appelez-nous	-
29	68129-21		Insert		Appelez-nous	-
30	60075-1		Cover		Appelez-nous	-
31	66834-1		Shelf, Crisper		Appelez-nous	-
32	60454-9		Trim, Crisper Shelf		Appelez-nous	-
33	12001957		Support, Crisper Shelf   (Replaces: 66105-1)				$ 3.35
34	60457-198		Pan, Crisper		Appelez-nous	-
35	WP489478		Screw   (Replaces: 400017-1)				$ 6.98
35	60138-6		Kickplate		Appelez-nous	-
36	60100-1		Clip, Kickplate				$ 5.85
37	W11117769		Leg, Leveling   (Replaces: 6012-8)			Immediately	$ 16.61
38	60571-59		Insert, Trim Escutcheon		Appelez-nous	-
39	29675-32		Ground Wire		Appelez-nous	-
39	402013-1		Screw		Appelez-nous	-
39	60583-1		Bracket, Switch		Appelez-nous	-
40	60585-1		Switch, Mullion Heater		Appelez-nous	-
41	68129-20		Insert		Appelez-nous	-
42	60096-4		Support		Appelez-nous	-
43	60122-1		Support, Shelf (upper)		Appelez-nous	-
43	60127-1		Rail, Support (lower)		Appelez-nous	-
43	60096-5		Support		Appelez-nous	-
44	60416-1		Shelf		Appelez-nous	-
45	60414-61		Trim		Appelez-nous	-
46	60414-61		Trim		Appelez-nous	-
47	60417-4		Shelf		Appelez-nous	-
48	29834-2		Wheel		Appelez-nous	-
49	29835-2		Pin, Wheel		Appelez-nous	-
50	60216-1		Clip		Appelez-nous	-
