SELECT A DIAGRAM

Diagram for 02 - Control Panel
02 - Control Panel

Diagram for 03 - Cooktop Parts
03 - Cooktop Parts

Diagram for 04 - Splasher Control
04 - Splasher Control

Diagram for 05 - Upper Oven Door Parts
05 - Upper Oven Door Parts

Diagram for 06 - Lower Oven Door Parts
06 - Lower Oven Door Parts

Diagram for 07 - Upper Body Parts
07 - Upper Body Parts

Diagram for 08 - Lower Body Parts
08 - Lower Body Parts

Diagram for 09 - Drawer Parts
09 - Drawer Parts

Diagram for 10 - Broiler Parts
10 - Broiler Parts


New Model Search:


1-888-572-4577
< Back to Home
Keyword Search:

Diagram # Part Number Description Series Availability Ships Price Add to Cart
1 740T305P01 Trim, Frame Appelez-nous -
2 3051255 Glass-control Pnl Appelez-nous -
3 3015593 Panel-control Mtg Appelez-nous -
4 5308010418 Switch-top Element (4) Special Order $ 169.83

5 5303051315 Switch-selector 6 Pos Lower Appelez-nous -
5 3051316 Switch-selector, 5 Pos, Upper Appelez-nous -
6 5303051320 Thermostat-oven Lower Appelez-nous -
6 5303202782 Thermostat-oven Upper Appelez-nous -
7 5303051248 Clock Appelez-nous -
8 5303208334 Knob-clock (3) Appelez-nous -
9 5308037896 Indicator Light Special Order $ 39.75

10 5308010401 Bushing-control Panel Glass Appelez-nous -
11 5303051442 Knob-thermostat Upr Appelez-nous -
11 3051820 Knob-thermostat Lwr Appelez-nous -
11 5303091393 Knob-switch S/u (4) Appelez-nous -
11 3051821 Knob-selector 5 Pos Appelez-nous -
11 5303091392 Knob-selector 6 Pos Appelez-nous -
10A 08011715 Clip-control Panel Frame Mounting (4) (non-illustrated) Appelez-nous -
2A 241T017P44 Fastener-clock (3) (non-illustrated) Appelez-nous -
9A 5303091462 Ind Light-250v (2) Appelez-nous -

    View Diagram in Separate Window     Print Icon   Print Part List

Diagram for 73-3957-23-06
