Diagram # Part Number Description Series Availability Ships Price Add to Cart
1 5303916770 Outer Panel-wheat Appelez-nous -
2 5303209943 Inner Panel Appelez-nous -
3 5308000176 Plug, Hinge, Wheat Appelez-nous -
4 5308000180 Plug, Handle, Wheat Appelez-nous -
5 5303209936 Nameplate Assy Appelez-nous -
6 3206153 Bearing-hinge (4) Appelez-nous -
7 3206158 Handle Appelez-nous -
8 5303209939 Upper Door Rack (2) Appelez-nous -
9 5303209940 Rack Door-small Appelez-nous -
10 3206149 Door, Dairy Appelez-nous -
11 5303209941 Gasket-door Appelez-nous -
12 3206165 Support-rs (2) In-Stock Immediately $ 8.19

13 3206287 Rack Door-lower (2) Appelez-nous -
12A 3206166 Support-ls (2) (non-illustrated) In-Stock Immediately $ 9.93

1A 5308000255 Stop-door (non-illustrated) Special Order $ 42.20

1B 5308011745 Screw Special Order $ 10.38

2A 218843801 Screw   (Replaces: 5303001001) Special Order $ 14.41

7A 5308011745 Screw Special Order $ 10.38


    View Diagram in Separate Window     Print Icon   Print Part List

Diagram for RC141MCH0
