Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	RA95060-1		Insulation Kit		Appelez-nous	-
1	69029-2-AM		Panel, F.f. Door (alm)		Appelez-nous	-
2	434003-506		Fastener		Appelez-nous	-
3	68656-4		Door Handle----na		Appelez-nous	-
4	66981-1		Bezel		Appelez-nous	-
6	WP489478		Screw   (Replaces: 400017-1)				$ 6.98
6	54485-1		Closer, Door		Appelez-nous	-
7	52613-1		Insulation, Closer		Appelez-nous	-
8	52614-1		Bracket, Closer		Appelez-nous	-
9	67874-1		Tapping Plate, Lower Hinge		Appelez-nous	-
9	65275-59		Screw		Appelez-nous	-
10	65944-12		Liner, Door		Appelez-nous	-
10	65275-5		Screw		Appelez-nous	-
11	66929-27		Gasket		Appelez-nous	-
12	66184-393		Door, Dairy		Appelez-nous	-
13	29936-2		Tray, Butter		Appelez-nous	-
14	59258-101		Trim, Door Shelf		Appelez-nous	-
15	66522-6		Organizer, Shelf		Appelez-nous	-
16	60066-1		Tray, Egg		Appelez-nous	-
17	68614-3		Trim, Handle Extension (upper)		Appelez-nous	-
18	68614-4		Trim, Handle Extension		Appelez-nous	-
19	53709-22		Hinge, Upper		Appelez-nous	-
19	WP3-24838-048		Screw   (Replaces: 9986-87)				$ 7.00
20	65003-3		Cover, Upper Hinge (alm)		Appelez-nous	-
21	WP52185-1		Washer   (Replaces: 52185-1)			Immediately	$ 9.47
22	67483-3		Washer, Lower Hinge   (Replaces: 67483-2)			Immediately	$ 45.86
23	65031-1		Shim, Upper Hinge		Appelez-nous	-
24	65275-51		Screw, Lower Hinge		Appelez-nous	-
24	68975-2		Hinge, Lower		Appelez-nous	-
25	68977-1		Pin, Hinge		Appelez-nous	-
26	69031-2		Shim		Appelez-nous	-
27	65246-1		Retainer				$ 5.04
28	68978-1		Cover, Lower Hinge (blk)		Appelez-nous	-
