Diagram # Part Number Description Series Availability Ships Price Add to Cart
1 5308017561 Control Box Appelez-nous -
2 215846602 Timer-defrost   (Replaces: 5300187484) In-Stock Immediately $ 28.20

3 5308000129 Light Socket Special Order $ 62.16

4 5303001179 Light Bulb Appelez-nous -
5 5308000068 Control, Temperature Special Order $ 166.58

6 5308037932 Sleeve, Plastic Appelez-nous -
7 5308000778 Knob-temperature Control Appelez-nous -
8 5303001252 Box-damper Assembly Appelez-nous -
9 5308000771 Air, Deflector Appelez-nous -
10 5308013429 Rivet-expansion Appelez-nous -
11 5316521701 Knob, Damper Control Appelez-nous -
12 5303001277 Ferrule, Outer Appelez-nous -
13 5303001276 Ferrule, Inner Appelez-nous -
14 5316465401 Cover-fan Assembly Appelez-nous -
15 218843801 Screw   (Replaces: 5303001001) Special Order $ 14.41

16 5308000124 Orifice Ring Special Order $ 53.58

17 5308000010 Fan Blade In-Stock Immediately $ 49.03

18 5303001226 Bracket-front Appelez-nous -
19 5300157666 Bushing - Motor Mtg, (2) Appelez-nous -
20 5300158289 Motor, Fan In-Stock Immediately $ 149.94

21 5303001227 Bracket-rear Appelez-nous -
22 5308000107 Bracket-connector Special Order $ 33.23

23 5316441928 Light Shield-refrigerator Appelez-nous -
24 5303001213 Support-light Shield Frzr & Refr Sect Appelez-nous -
25 5316445232 Light Shield, Freezer Appelez-nous -
13A 5303001280 Gasket-ferrule (non-illustrated) Appelez-nous -
14A 5304455650 Screw   (Replaces: 5308016566) Special Order $ 14.18

1A 5308010253 Screw-box Mounting (2) (non-illustrated) Appelez-nous -
1B 3001269 Insulator-box Rear (non-illustrated) Appelez-nous -
2A 5304455649 Screw   (Replaces: 5303001259) Special Order $ 17.01

5A 5303001260 Screw Special Order $ 6.73

5B 5303015098 Wiring Harness-control (non-illustrated) Appelez-nous -
8A 5304455650 Screw   (Replaces: 5308016566) Special Order $ 14.18


    View Diagram in Separate Window     Print Icon   Print Part List

Diagram for RSG192GCH1A
