01 - Control Assy


02 - Door Assy


03 - Electrical Assy


04 - Interior Assy


05 - Oven Cavity Assy


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	C8708502		Grille Air Inlet		Appelez-nous	-
2	WP489349		Screw   (Replaces: M0216515)			Immediately	$ 7.09
3	B5714801		Filter		Appelez-nous	-
4	D7732802		Basepan Weld		Appelez-nous	-
5	D7573603		Chassis		Appelez-nous	-
6	D7686906		Transformer		Appelez-nous	-
7	M0253543		Screw K		Appelez-nous	-
8	D8547924		Capacitor		Appelez-nous	-
9	A4055405		Strap, Capacitor		Appelez-nous	-
10	A3197701		Washer-u Type		Appelez-nous	-
11	M0216517		Screw		Appelez-nous	-
12	WP13091701		Rectifier   (Replaces: B8383102)				$ 31.71
13	B8354401		Strain Relief		Appelez-nous	-
14	D7718022		H.v. Lead Kit		Appelez-nous	-
14	D7365138		Wire Jumper		Appelez-nous	-
15	D7681501		Triac				$ 44.05
16	C8775302		Oven Mtg Plate		Appelez-nous	-
17	D7718023		Wire, Jumper		Appelez-nous	-
17	D7718024		Wire Jumper		Appelez-nous	-
18	C8901505		Transformer		Appelez-nous	-
19	B5696105		Bracket-line Filter		Appelez-nous	-
20	M0321039		Sleeve, Vinyle		Appelez-nous	-
21	B5669006		Cord Power		Appelez-nous	-
22	D7718018		Jumper Wire		Appelez-nous	-
23	C8870702		Gasket, Base Pan		Appelez-nous	-
24	C8870703		Gasket, Base Pan		Appelez-nous	-
25	C8986502		Strain Relief Panel		Appelez-nous	-
26	M0102305		Clamp, Tube		Appelez-nous	-
27	B8390801		Washer		Appelez-nous	-
28	B8391703		Board, Fuse		Appelez-nous	-
29	WP3388228		Screw Xxx   (Replaces: M0216703)				$ 6.26
30	M0293502		Stud-self Clinch		Appelez-nous	-
31	B8392501		Guide, Filter		Appelez-nous	-
32	C8959701		Filter, Line		Appelez-nous	-
33	A3204901		Thermal Compound K		Appelez-nous	-
34	C8847903		Air Inlet Weld		Appelez-nous	-
35	C8969201		Terminal Block		Appelez-nous	-
36	C8970201		Capacitor Assy		Appelez-nous	-
37	B8364201		Spring		Appelez-nous	-
40	M0251002		Screw		Appelez-nous	-
40	10172901		Snubber Assembly		Appelez-nous	-
41	M1014102		Clip Cord		Appelez-nous	-
42	M0282005		Nut K				$ 7.07
43	WPM0805102		Fuse 15 Amp   (Replaces: M0805102)				$ 21.25
