Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	5349007601		Cover-fan		Appelez-nous	-
2	5316266315		Knob-damper Cntrl		Appelez-nous	-
3	5303001028		Push-nut		Appelez-nous	-
4	5303001331		Damper, Fan				$ 31.71
5	5308000010		Fan Blade			Immediately	$ 49.03
6	218843801		Screw   (Replaces: 5303001001)				$ 14.41
7	5308000124		Orifice Ring				$ 53.58
8	5300157666		Bushing - Motor Mtg, (2)		Appelez-nous	-
9	5303001226		Bracket-front		Appelez-nous	-
10	5308009771		Cover-evap Coil		Appelez-nous	-
11	5303208309		Plug, Short Test Hole				$ 45.50
12	5303018193		Plug-decorative		Appelez-nous	-
13	5300158289		Motor, Fan			Immediately	$ 149.94
14	5303001227		Bracket-rear		Appelez-nous	-
15	5308000107		Bracket-connector				$ 33.23
16	5303210353		Screw-bracket Mounting		Appelez-nous	-
17	5303001470		Drain Trough		Appelez-nous	-
18	5308000097		Support-coil Cvr (2)		Appelez-nous	-
19	5303001198		Tube, Rubber (2)		Appelez-nous	-
20	5303001286		Ferrule-inner		Appelez-nous	-
21	5303001287		Ferrule-outer		Appelez-nous	-
22	5303001388		Plug, White (2)				$ 2.60
23	5303210377		Defrost Drain Tube-w/ Seal Ring				$ 109.31
24	5308012843		Hinge-top				$ 71.47
25	5303001037		Shim, Top Hinge				$ 12.39
26	5308010092		Cabinet Base		Appelez-nous	-
27	5303205540		Leveling Screw (2)		Appelez-nous	-
28	5308003584		Anchor Nut (2)				$ 7.30
29	5303001478		Plug, Hinge Hole		Appelez-nous	-
30	5303202834		Bracket, Bottom Hinge				$ 89.41
31	5303001323		Shim, Bottom Hinge		Appelez-nous	-
32	5303001321		Pin, Bottom Hinge				$ 17.25
33	5308000186		Washer-nylon (3)			Immediately	$ 6.02
35	5303001369		Bracket- Center Hinge		Appelez-nous	-
36	5308000184		Pin-center Hinge				$ 8.87
37	5303202336		Corner Trim-white (4)		Appelez-nous	-
38	5308012820		Hinge Cover, White		Appelez-nous	-
39	5308009773		Roller Assy, Rear, (2)		Appelez-nous	-
40	5308009762		Bolt-1/4-28 X 1/2 (2)		Appelez-nous	-
41	5308009760		Roller Assy-front, (2)		Appelez-nous	-
42	5308009790		Spring, Roller Adj (2)				$ 4.30
43	5308013678		Support-roller (2)		Appelez-nous	-
44	5308009761		Bolt, Roller Adj (2)				$ 18.61
45	5308011326		Washer-nylon (2)				$ 9.87
46	5303207353		Seal Ring				$ 6.81
47	5308000056		Drain Spout				$ 11.66
48	5303001361		Push Pin		Appelez-nous	-
*35191	5308016571		Plug-liner (8)				$ 4.79
*35191	5308012296		Tapping Plate (4)				$ 47.44
10A	5303209814		Nut U, Type (2) (non-illustrated)		Appelez-nous	-
10B	5304455650		Screw   (Replaces: 5308016566)				$ 14.18
1A	G000187640		Label-fan Cover		Appelez-nous	-
1B	5304455650		Screw   (Replaces: 5308016566)				$ 14.18
24A	241710601		Screw   (Replaces: 5303001479)				$ 13.46
30A	5303001320		Screw, Hinge Mounting (2) (non-illustrated)		Appelez-nous	-
31A	5308012296		Tapping Plate (2) (non-illustrated)				$ 47.44
35A	5308012258		Screw				$ 2.25
40A	5304455651		Screw   (Replaces: 5303001343)				$ 14.41
