Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	M0305202		Resistor A		Appelez-nous	-
2	D7369201		Transformer		Appelez-nous	-
3	M0216517		Screw		Appelez-nous	-
4	M0218116		Screw		Appelez-nous	-
5	M0320901		Terminal		Appelez-nous	-
6	D7351801		Transformer Mounting Plate		Appelez-nous	-
7	C8807803		Filament Transformer		Appelez-nous	-
8	B5767802		Kit, Diode		Appelez-nous	-
9	C8790501		Capacitor Assy		Appelez-nous	-
10	R0160021		Capacitor Assy		Appelez-nous	-
11	M0254452		Screw		Appelez-nous	-
12	M0254409		Screw		Appelez-nous	-
13	M0325301		Insulator, Term. K		Appelez-nous	-
14	A3257001		Strap-capacitor		Appelez-nous	-
15	D7292618		Jumper Wire		Appelez-nous	-
15	D7365101		Jumper Wire		Appelez-nous	-
15	D7292619		Jumper Wire		Appelez-nous	-
16	D7292617		Wire, Jumper, Rectifiers Fuse		Appelez-nous	-
16	D7292620		Jumper Wire		Appelez-nous	-
17	M0308102		Fuse		Appelez-nous	-
18	M0321701		Sleeve		Appelez-nous	-
19	M0305009		Resistor A		Appelez-nous	-
20	M0305402		Resistor Fuse Kit		Appelez-nous	-
21	M0305204		Resistor		Appelez-nous	-
22	M0308101		Fuse				$ 9.87
23	C8806401		Terminal Bd		Appelez-nous	-
24	C8761704		Magnetron		Appelez-nous	-
25	A4539601		Pop Rivet		Appelez-nous	-
26	B5725102		Clip		Appelez-nous	-
27	B5665815		Thermal Cut Out		Appelez-nous	-
