New Model Search:
| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | 3206121 | Mullion, White |
|
- | |||||
| 3 | 5303206754 | Washer No. 10 Flat, 7/32 X 7/16 Od, Steel |
|
- | |||||
| 4 | 5303200464 | Spacer-mullion Mtg, Steel |
|
- | |||||
| 5 | 5303281861 | Heater-mullion |
|
- | |||||
| 6 | 5308003604 | Strap, Mullion Mtg |
|
- | |||||
| 7 | 5303001380 | Screw |
|
- | |||||
| 7 | 5303270919 | Top Panel-refr |
|
- | |||||
| 8 | 5303270921 | Divider, Styrofoam |
|
- | |||||
| 8 | 5303272865 | Harness-wiring, Control/divider (non-illustrated) |
|
- | |||||
| 8 | 3205266 | Protector-edge (non-illustrated) |
|
$ 80.09 | |||||
| 9 | 5303270920 | Bottom Panel-frzr |
|
- | |||||
| 10 | 5303001324 | Tray-ice, Plastic |
|
- | |||||
| 11 | 5303283580 | Shelf-freezer |
|
- | |||||
| 12 | 5308014667 | Deflector, Air |
|
- | |||||
| 12 | 5303001449 | Seal-air Deflector (non-illustrated) |
|
$ 2.12 | |||||
| 13 | 5303001448 | Cover-air Deflector |
|
- | |||||
| 13 | 5303200590 | Extension, Air Deflector, With Insulation (non-illustrated) |
|
- | |||||
| 14 | 5309918806 | Switch, Light |
|
Immediately | $ 21.97 | ||||
| 15 | 5303001179 | Light Bulb/lamp |
|
- | |||||
| 17 | 08016567 | Nut-anchor, Control Box Mtg (non-illustrated) |
|
- | |||||
| 17 | 5303281832 | Box-control |
|
- | |||||
| 18 | 5303209251 | Knob-temp Control |
|
- | |||||
| 21 | 5303001260 | Screw |
|
$ 6.73 | |||||
| 21 | 5303018894 | Control-temperature |
|
- | |||||
| 22 | 5303270923 | Housing, Cont Cap Tube |
|
- | |||||
| 23 | 5304455649 | Screw (Replaces: 5303001259) |
|
$ 17.01 | |||||
| 23 | 215846602 | Timer (Replaces: 5300187484) |
|
Immediately | $ 28.20 | ||||
| 24 | 5303283125 | Shelf-sliding, Refr, (2) |
|
- | |||||
| 25 | 5303270897 | Cover-crisper Pan |
|
$ 275.73 | |||||
| 26 | 5303209937 | Pan-crisper, Full-width |
|
$ 231.16 | |||||
| 28 | 3201150 | Cap-protector |
|
$ 4.57 | |||||
| 46 | 5303281864 | Front-crisper Pan, Full |
|
- | |||||
| 59 | 3206134 | Screw-hinge/mullion, Acorn Hx Wsh Hd, 10-24(23) X 1 |
|
- | |||||
| 81 | 5304455650 | Screw (Replaces: 5308016566) |
|
$ 14.18 | |||||
| 16A | 218906802 | Socket-light/lamp (Replaces: 5308000815) |
|
$ 17.72 |
