SELECT A DIAGRAM

Diagram for 02 - Freezer Door Parts
02 - Freezer Door Parts

Diagram for 03 - Refrigerator Door Parts
03 - Refrigerator Door Parts

Diagram for 04 - Cabinet Parts
04 - Cabinet Parts

Diagram for 05 - Shelves And Supports
05 - Shelves And Supports

Diagram for 06 - Refrigerator Control Assembly, Damp
06 - Refrigerator Control Assembly, Damp

Diagram for 07 - System And Automatic Defrost Parts
07 - System And Automatic Defrost Parts


New Model Search:


1-888-572-4577
< Back to Home
Keyword Search:

Diagram # Part Number Description Series Availability Ships Price Add to Cart
1 3001720 Freezer Door-wheat Appelez-nous -
2 5303200272 Door Closer Appelez-nous -
3 3001020 Screw - Mounting Appelez-nous -
4 5303001022 Hinge Bearing, Upper Appelez-nous -
5 5303200474 Gasket-freezer Appelez-nous -
6 5303016719 Door Panel-inner Appelez-nous -
7 5303016720 Door Rack (6) Appelez-nous -
8 5303016721 Support Rs (6) Appelez-nous -
9 5316108004 Support Ls (6) Appelez-nous -
10 5315230801 Plug-door Bottom Appelez-nous -
11 5303007739 Insulation, Bulk Appelez-nous -
12 G175666-20 Grip-handle Appelez-nous -
13 5303001014 End - Handle Top Appelez-nous -
14 5303001015 End - Handle Bottom Special Order $ 74.29

15 5308011745 Screw Special Order $ 10.38

16 5308000790 Bumper, Light Switch Special Order $ 3.86

*40326 218843801 Screw   (Replaces: 5303001001) Special Order $ 14.41

4A 5308012007 Hinge Bearing - Lower (non-illustrated) Appelez-nous -
6A 218843801 Screw   (Replaces: 5303001001) Special Order $ 14.41


    View Diagram in Separate Window     Print Icon   Print Part List

Diagram for 95-1967-66-04
