| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | 5303161221 | Stud Bolt |
|
$ 16.38 | |||||
| 2 | 5303280324 | Drive Block |
|
$ 39.38 | |||||
| 4 | 5303280325 | Shim |
|
- | |||||
| 5 | 5303161307 | Seal-upper, Lip |
|
Immediately | $ 21.27 | ||||
| 6 | 5303161223 | Retaining Ring (2) |
|
$ 10.24 | |||||
| 10 | 5308950197 | Water Seal Kit |
|
$ 73.03 | |||||
| 11 | 5303161224 | Pipe Plug |
|
- | |||||
| 12 | 08002804 | Screw |
|
- | |||||
| 13 | 5308015778 | Gasket |
|
$ 33.18 | |||||
| 14 | 5308011268 | Gear-sector |
|
- | |||||
| 15 | 5303161169 | Rod-connecting |
|
- | |||||
| 16 | 5308015496 | Gear-crank |
|
- | |||||
| 17 | 5308014905 | Shaft Assy. - Lower |
|
- | |||||
| 18 | 5303161226 | Thrust Washer |
|
- | |||||
| 19 | 5303161227 | Dowel Pin |
|
- | |||||
| 21 | 5303912535 | Housing Lower (includes 13) |
|
- | |||||
| 22 | 5308950058 | Bearing Housing/ Lgs Spring Pkg. |
|
- | |||||
| 25 | 5308015536 | Retaining Ring |
|
- | |||||
| 26 | 5308027582 | Screw |
|
- | |||||
| 28 | 5303207426 | Spacer |
|
$ 9.21 | |||||
| 30 | 5308002475 | Spacer Washer |
|
- | |||||
| 31 | 5303161226 | Thrust Washer |
|
- | |||||
| 32 | 5303161173 | Seal-lower Lip |
|
$ 9.36 | |||||
| 33 | 5303161174 | Spring-small L.g.s. |
|
$ 22.10 | |||||
| 34 | 5303161175 | Gear-idler |
|
- | |||||
| 35 | 5308014910 | Shaft Assy. - Agitator |
|
- | |||||
| 36 | 5303937039 | Housing-upper-gasket |
|
- | |||||
| 38 | 5303272073 | Slinger |
|
$ 29.82 | |||||
| 40 | 5303161232 | Thrust Washer |
|
- | |||||
| 41 | 134736400 | Transmission-complete (Replaces: 5308057579) |
|
$ 875.74 | |||||
| 42 | 5308057430 | Washer |
|
- | |||||
| *50477 | 3005242 | Oil-transmission (1 Qt) |
|
- | |||||
| *50477 | 5303161182 | Sleeve-clutch Coil |
|
- |
