02 - Chest Freezer Parts


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
2	06599967		Grommet		Appelez-nous	-
5	5303204202		Lid-exterior-almond		Appelez-nous	-
7	5309948660		Hinge		Appelez-nous	-
11	08009392		Gasket Handle		Appelez-nous	-
12	08037982		Handle Recessed		Appelez-nous	-
22	08037851		Screw				$ 3.57
25	5306593887		Plug, Drain, Liner		Appelez-nous	-
26	5306599932		Plug Drain Shell		Appelez-nous	-
28	5303207455		Insulation Lid		Appelez-nous	-
30	5308037991		Gasket-brown		Appelez-nous	-
39	5303212828		Clip,panel				$ 16.63
43	5309950602		Screw				$ 5.30
45	5300120780		External Condenser-(not Original Equipment-service Repla		Appelez-nous	-
55	5308013601		Cold Control		Appelez-nous	-
57	5308008778		Grommet Comp Mtg		Appelez-nous	-
59	5309950343		Clip Comp Mtg		Appelez-nous	-
61	5303305677		Drier   (Replaces: 5300152474)			Immediately	$ 31.67
63	5303017718		Clamp-wires		Appelez-nous	-
64	3018261		Wiring Harness		Appelez-nous	-
66	3017761		Run Capacitor		Appelez-nous	-
67	5303206808		Harness-capacitor-note		Appelez-nous	-
68	5303208622		Clip Grounding		Appelez-nous	-
69	5305878546		Spacer Condenser				$ 7.23
70	5303208881		Knob Control		Appelez-nous	-
79	3204179		Nameplate		Appelez-nous	-
80	3204180		Insert Nameplate		Appelez-nous	-
84	5303018277		Basket-(not Original Equipment-customer Purchase Only.)		Appelez-nous	-
88	08017037		Retainer Access Panel				$ 3.26
93	5300186041		Compressor		Appelez-nous	-
94	5303209289		Relay		Appelez-nous	-
95	5303209290		Overload		Appelez-nous	-
96	5303209294		Clip-overload		Appelez-nous	-
97	5303209292		Cover-terminal		Appelez-nous	-
98	5303209293		Clamp Cover		Appelez-nous	-
99	5303018270		Breaker-corner		Appelez-nous	-
100	5303018273		Breaker-end		Appelez-nous	-
101	5303018320		Breaker-front & Rear		Appelez-nous	-
102	5303208663		Plug-indicator		Appelez-nous	-
45A	06599553		Clip, Wires		Appelez-nous	-
