| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | 215776715 | Gasket-frzr Door, White, Magnetic |
|
- | |||||
| 2 | 215732417 | Gasket, Refr Door, White, Magnetic |
|
- | |||||
| 3 | 5303292376 | Panel-inner Door, Refr |
|
- | |||||
| 4 | 215366050 | Rack-door, Full-width |
|
- | |||||
| 5 | 215473602 | Support-door Rack, Rh/lh (Replaces: 215473601) |
|
Immediately | $ 11.58 | ||||
| 7 | 215058105 | Door - Dairy |
|
- | |||||
| 9 | 5303292371 | Panel, Inner Door, Frzr |
|
- | |||||
| 10 | 5303292413 | Plug-button, White, Hinge Brg Hole |
|
$ 4.94 | |||||
| 11 | 218240801 | Panel-frzr Door, White, W/foam Insulatn |
|
- | |||||
| 12 | 215366301 | Frame - Nameplate,white |
|
- | |||||
| 13 | 5303289522 | Door Stop |
|
$ 40.17 | |||||
| 14 | 215352101 | Plug-button, White, Handle Mtg |
|
- | |||||
| 15 | 218240901 | Panel-refr Door, White, W/foam Insulatn |
|
- | |||||
| 18 | 215915521 | Handle-door, White, Refr, W/ Handle Ends |
|
- | |||||
| 21 | 218214301 | Screw-handle Mtg, White, Cr Oval Head, 8-18 X 5/8 |
|
- | |||||
| 13A | 215030001 | Door Stop, White, Frzr |
|
$ 29.61 | |||||
| 14A | 240494001 | Plug-button,white ,refr Door Front , (Replaces: 215352201) |
|
Immediately | $ 18.20 | ||||
| 18A | 215915523 | Handle-door, White, Frzr, W/ Handle Ends |
|
- | |||||
| 21A | 215218600 | Screw-door Stop Mtg,torx Flat Head 10-16 X 3/4 |
|
- | |||||
| NI | 5315340712 | Tape, Adhesive, 12`` Lg, Foam, Double-faced (non-illustrated) |
|
- | |||||
| NI | 215220302 | Label-nameplate, Gray/white Ltrs (non-illustrated) |
|
- |
