01 - Control Panel


02 - Oven Door


03 - Oven, Lit/optional


04 - Wiring Harness, Optional


05 - Cooktops


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	3148444		End Cap (black, Rh)		Appelez-nous	-
1	3148445		End Cap (black, Lh)		Appelez-nous	-
1	3150013		End Cap (white Lh)		Appelez-nous	-
1	3150014		End Cap (white, Rh)		Appelez-nous	-
2	3184395		Bracket, Control		Appelez-nous	-
3	3148616		Rail, Top		Appelez-nous	-
3	98520		Screw (2)		Appelez-nous	-
4	98520		Trim, Center (screw (2))		Appelez-nous	-
4	3149350		Trim, Center (white)		Appelez-nous	-
4	3148620		Trim, Center (black)		Appelez-nous	-
5	3148472		(trim, Vent Door Rosemont Grey) (right Hand)		Appelez-nous	-
5	3148471		(trim, Vent Door Rosemont Grey) (left Hand)		Appelez-nous	-
5	3148697		Trim, Vent Door Black (left Hand)		Appelez-nous	-
5	3148698		Trim, Vent Door Black (right Hand)		Appelez-nous	-
6	3183506		Door, Vent (brushed Aluminum)		Appelez-nous	-
6	342043		Door, Vent (screw (2))		Appelez-nous	-
6	3183505		Door, Vent (black)		Appelez-nous	-
7	3148618		Trim, Bottom		Appelez-nous	-
7	342043		Screw (4)		Appelez-nous	-
8	98520		Screw		Appelez-nous	-
8	3149142		Shield, Air		Appelez-nous	-
9	3182302		Panel, Control (white)		Appelez-nous	-
9	3182301		Panel, Control (black)		Appelez-nous	-
10	98520		Control, Electronic (screw (2))		Appelez-nous	-
10	3169257		Control, Electronic (white)		Appelez-nous	-
10	3169256		Control, Electronic (black)		Appelez-nous	-
11	3183992		Shield, Control		Appelez-nous	-
12	488946		Strain Relief   (Replaces: 255564)				$ 18.41
12	WP488729		Screw   (Replaces: 3148107)			Immediately	$ 7.01
14	3149900		Trim, End Cap (black)		Appelez-nous	-
14	3149901		Trim, End Cap (white)		Appelez-nous	-
15	3182718		Switch, Rocker (white)		Appelez-nous	-
15	3182717		Switch, Rocker (black)		Appelez-nous	-
16	WP965173		Screw,   (Replaces: 246132)			Immediately	$ 9.65
16	312752		Support, Top Rail		Appelez-nous	-
