Diagram # Part Number Description Series Availability Ships Price Add to Cart
1 35-2653 Control Panel Appelez-nous -
2 25-7852 Speedclip, Rr Shld To End Cap Appelez-nous -
2 WP33002917 Screw   (Replaces: 25-7435) In-Stock Immediately $ 6.90

3 34-9487 Plate, Reinforcement Appelez-nous -
3 25-7649 Screw Appelez-nous -
3 35-2669 Cap, End (lt)(wht) Appelez-nous -
3 35-2668 Cap, End (rt)(wht) Appelez-nous -
3 WP33002917 Screw   (Replaces: 25-7435) In-Stock Immediately $ 6.90

3 25-7697 Screw Appelez-nous -
3 25-7702 Speedclip, End Cap To Ctrl Pnl Appelez-nous -
3 25-7851 Speedclip, End Cap To Top Appelez-nous -
3 25-7852 Speedclip, Rr Shld To End Cap Appelez-nous -
4 53-0278 Trim, End Cap (lt) Appelez-nous -
4 25-7760 Screw Appelez-nous -
4 53-0277 Trim, End Cap (rt) Appelez-nous -
5 WP90767 Screw   (Replaces: 25-3092) In-Stock Immediately $ 7.04

5 25-7702 Speedclip, End Cap To Ctrl Pnl Appelez-nous -
6 35-2680 Control Shield Appelez-nous -
7 35-2688 Shield, Control Panel (rear) Appelez-nous -
7 WP12990527 Screw, Sems   (Replaces: 25-3457) In-Stock Immediately $ 7.15

7 25-7583 Plastic Nut Appelez-nous -
7 WP90767 Screw   (Replaces: 25-3092) In-Stock Immediately $ 7.04

8 35-2748CP Timer   (Replaces: 35-2211) Appelez-nous -
9 25-0205 Screw Appelez-nous -
10 35-2671 Skirt Assy Appelez-nous -
11 35-2672 Timer Knob Appelez-nous -
12 35-2198 Switch Appelez-nous -
13 WP90767 Screw   (Replaces: 25-3092) In-Stock Immediately $ 7.04

13 33-6623 Bracket Appelez-nous -
14 35-0691-01 Signal Light Appelez-nous -
14 35-0691-04 Signal Light Appelez-nous -
14 35-0691-06 Light Assy Appelez-nous -
14 35-0691-05 Light Assy Appelez-nous -
15 35-2656-04 Pushbutton (super Scrub) Appelez-nous -
15 35-2656-05 Pushbutton (non Color Fast) Appelez-nous -
15 35-2656-06 Pushbutton (energy Saver) Appelez-nous -
15 35-2656-07 Pushbutton (delicate) Appelez-nous -
15 35-2656-08 Pushbutton (knits & Blankets) Appelez-nous -
15 35-2656-01 Pushbutton (super Scrub) Appelez-nous -
15 35-2656-02 Pushbutton (non Color Fast) Appelez-nous -
15 35-2656-03 Pushbutton (energy Saver) Appelez-nous -
16 35-2164 Lens Appelez-nous -
16 35-2655 Bezel - P.b. Appelez-nous -
16 25-7882 Palnut Appelez-nous -
16 35-0690 Lens Appelez-nous -
17 35-2257 Terminal Block Appelez-nous -
18 25-7649 Screw Appelez-nous -
19 WP90767 Screw   (Replaces: 25-3092) In-Stock Immediately $ 7.04

19 WP21001554 Pressure Switch   (Replaces: 35-2145) Special Order $ 143.59

20 35-2676 Knob, Selector Appelez-nous -
21 35-0688 Pb Switch Appelez-nous -
22 33-6621 Bracket, Switch Appelez-nous -
23 25-7712 Screw Appelez-nous -
23 WP90767 Screw   (Replaces: 25-3092) In-Stock Immediately $ 7.04

24 33-8541 Switch Pad Appelez-nous -
24 35-2666 Manual, U&c Insert Appelez-nous -

    View Diagram in Separate Window     Print Icon   Print Part List

Diagram for W20JN5
