01 - Control Panel Parts


02 - Cabinet And Air Flow Parts


03 - Interior And Ventilation Parts


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	4713-001013		Lamp			Immediately	$ 18.00
2	DE47-00006A		Holder, Lamp				$ 17.58
3	DE59-50002A		Capacitor, Motor			Immediately	$ 27.34
4	DE61-00869A		Bracket, Duct (u)		Appelez-nous	-
5	DE97-00597A		Assy, Duct Upper		Appelez-nous	-
6	555555		Thermostat   (Replaces: DE47-20196A)				$ 151.94
7	W10182257		Motor, Fan Assy				$ 38.66
8	555555		Filter, Charcoal   (Replaces: DE63-00367E)				$ 151.94
9	DE96-00218A		Cord, Power				$ 78.75
10	DE92-90508A		Holder Nut, Assy			Immediately	$ 17.58
11	DE64-01429A		Case, Outer (black, Ss Model)				$ 179.17
11	DE64-01429B		Case, Outer (white)		Appelez-nous	-
11	DE64-01429C		Case, Outer (bisque)		Appelez-nous	-
12	W10197773		Damper, Assembly				$ 29.38
13	DE72-40022A		Plate, Damper			Immediately	$ 12.07
14	555555		Plate, Mounting   (Replaces: DE70-00378A)				$ 151.94
15	DE96-00509A		Main Harness		Appelez-nous	-
16	DE92-90505G		Install, Hardware				$ 29.82
NI	DE68-03144B		Template, Top		Appelez-nous	-
NI	W10197644		Template, Wall		Appelez-nous	-
