New Model Search:
| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 39 | 5303001037 | Shim - Upper Hinge |
|
$ 12.39 | |||||
| 42 | 3206143 | Screw-lwr Hinge Mtg, Hex Washer Hd, 1/4-20 X 5/8, (4) |
|
- | |||||
| 43 | 5300188673 | Roller Assy-front (2) |
|
- | |||||
| 44 | 5303283014 | Roller Assy-rear, Metal Hsg, (2) |
|
- | |||||
| 45 | 5304455651 | Screw (Replaces: 5303001343) |
|
$ 14.41 | |||||
| 56 | 5303001321 | Pin-lower Hinge |
|
$ 17.25 | |||||
| 58 | 5308002748 | Screw |
|
- | |||||
| 59 | 3206134 | Screw-hinge/mullion, Acorn Hx Wsh Hd, 10-24(23) X 1 |
|
- | |||||
| 78 | 5303210353 | Screw, Connectr Brkt, Hex Washer Head, 8, 32(ca) X 1/2 |
|
- | |||||
| 83 | 5308000107 | Bracket-connector |
|
$ 33.23 | |||||
| *59111 | 5308016571 | Plug-button, Liner |
|
$ 4.79 | |||||
| 38A | 5308012296 | Tapping Plate, Upper Hinge, (2) (non-illustrated) |
|
$ 47.44 | |||||
| 43A | 3051070 | Screw-rlr/plate Mtg, Spcl Hx Wshr Hd, 10-32 X 1/2 (non-illustrated) |
|
- | |||||
| 43B | 5308009760 | Roller, (2) (non-illustrated) |
|
- | |||||
| 43C | 5308009790 | Spring-roller Adj, (2) (non-illustrated) |
|
$ 4.30 |
