SELECT A DIAGRAM

01 - Top Assy.\burner Box


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	3601F164-80		Baffle, Ceramic Top	01	Appelez-nous	-
2	3601F173-51		Baffle, Heat----na	01	Appelez-nous	-
3	4011F136-45		Bottom, Burner Box	01	Appelez-nous	-
4	4016F023-45		Bottom, Burner Box-sides	01	Appelez-nous	-
5	3801F188-45		Bracket, Light Indicator	01	Appelez-nous	-
6	W10823707		Element, Giant   (Replaces: 7406P057-60)	01		Immediately	$ 316.13
7	W10823704		Element, Std   (Replaces: 7406P058-60)	01		Immediately	$ 309.01
8	4870F012-60		Tape, Foam (1/2``x102``)	01	Appelez-nous	-
8	7746P029-60		Frame, Main Top	01	Appelez-nous	-
9	WA906B		Scraper, Razor   (Replaces: 8312P001-60)	01		Immediately	$ 4.86
9	CERAMABRYTE		Cleaner, Elco   (Replaces: 8308P002-60)	01		Immediately	$ 9.95
9	7719P062-60		Nameplate, Admiral (blk)	01	Appelez-nous	-
9	8270P067-60		Tape, Silicone Seal	01	Appelez-nous	-
9	7918P039-60		Glass Main Top	01	Appelez-nous	-
10	8008P033-60		Grommet	01	Appelez-nous	-
11	7737P029-60		Knob, Switch	01			$ 18.07
12	7407P074-60		Light, Indicator (hot Surface)	01	Appelez-nous	-
13	3605F175-45		Plate, Switch Mtg	01	Appelez-nous	-
14	3804F092-45		Retainer, Main Top Glass	01	Appelez-nous	-
NI	3414F035-44		Tubing, Conduit (flexible)	01	Appelez-nous	-
NI	5125A087-60		Wire Harness Complete	01	Appelez-nous	-
NI	5125A327-60		Wires, Loose	01	Appelez-nous	-
NI	5170D131-60		Harness, Wire	01	Appelez-nous	-
NI	8018P001-60		Sleeve, Tube	01	Appelez-nous	-
NI	WP74004005		Screw   (Replaces: 7101P076-60)	01			$ 6.95
NI	7101P113-60		Screw	01	Appelez-nous	-
NI	3807F326-80		Support, Ceramic Element	01	Appelez-nous	-
NI	8004P015-60		Support, Element	01	Appelez-nous	-
NI	7403P266-60		Switch, Infinite (1400w)	01	Appelez-nous	-
NI	7403P267-60		Switch, Infinite (2400w)	01	Appelez-nous	-
NI	7212P030-60		Seal, Gasket Inf. Sw.	01	Appelez-nous	-
NI	7417P004-60		Connector, Right Ang	01	Appelez-nous	-

    View Diagram in Separate Window       Print Part List
