SELECT A DIAGRAM

01 - Cabinet (rev. A-c)


02 - Control Panel (rev. A-c)


03 - Door (rev. A-c)


04 - Gas Carrying (rev. A-c)


05 - Motor & Drive (rev. A-c)


06 - Tumbler (rev. A-b)


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	W11117769		Leg, Leveling   (Replaces: 63-5834)			Immediately	$ 16.61
2	53-0120		Clip, Front Panel				$ 11.32
3	16515		Clip, Wiring   (Replaces: 25-7027)				$ 17.60
4	53-0153		Shield, Wiring		Appelez-nous	-
4	LA-1004		Motor Mtg. Kit (dryer)		Appelez-nous	-
4	WP90767		Screw   (Replaces: 25-7741)			Immediately	$ 7.04
5	53-1041		Motor Asm	A	Appelez-nous	-
5	W10410996		Motor & Pulley Assy (115v,60hz   (Replaces: 53-2275)			Immediately	$ 274.59
6	53-0693		Switch, Motor		Appelez-nous	-
7	53-1932		Motor Mtg. Brkt.	A	Appelez-nous	-
7	25-7811		Screw		Appelez-nous	-
7	53-0852		Motor Bracket		Appelez-nous	-
8	WP660658		Clamp, Motor   (Replaces: 53-0214)				$ 7.05
8	25-7699		Strain Relief		Appelez-nous	-
8	25-7674		Screw		Appelez-nous	-
9	WP31001344		Pulley, Idler   (Replaces: 53-1628)			Immediately	$ 42.91
9	25-7815		Washer	A	Appelez-nous	-
9	53-0764		Idler Arm	B	Appelez-nous	-
9	WP53-2287		Idler Assy.   (Replaces: 53-2287)	A			$ 125.71
9	53-1650		Idler Assy		Appelez-nous	-
9	25-7957		Pushnut	A			$ 6.41
10	53-2209		Spring, Idler	A	Appelez-nous	-
10	53-1648		Idler Spring		Appelez-nous	-
11	53-0134		Duct, Exhaust		Appelez-nous	-
11	WP90767		Screw   (Replaces: 25-2134)			Immediately	$ 7.04
12	53-1801		Housing, Blower	A	Appelez-nous	-
12	53-0774		Blower Housing		Appelez-nous	-
13	12001324		Seal, Blower Housing   (Replaces: 53-0203)				$ 187.37
14	53-0106		Blower Wheel				$ 58.02
15	WP312967		Clamp   (Replaces: 25-7823)			Immediately	$ 10.68
16	25-7855		Ring, Retaining				$ 8.67
17	53-1934		Cover, Blower Housing	A	Appelez-nous	-
17	WP33002917		Screw   (Replaces: 25-7807)			Immediately	$ 6.90
17	53-1026		Guide, Vane Inlet		Appelez-nous	-
17	WP90767		Screw   (Replaces: 25-2134)			Immediately	$ 7.04
17	53-1023		Blower Cover		Appelez-nous	-
18	WP53-1107		Thermostat, Control (146/121)   (Replaces: 53-1107)				$ 81.25
19	W10124350		Not Required Part Or See Note		Appelez-nous	-
20	WP31001356		Rh Gld Cushion   (Replaces: 53-0182)				$ 76.16
21	WP31001469		Rh Cyl Glide   (Replaces: 53-0183)				$ 66.66
21	W10124350		Not Required Part Or See Note Not Required		Appelez-nous	-
22	W10124350		Not Required Part Or See Note Not Required		Appelez-nous	-
23	LA-1008		Rr Roller Kit				$ 66.73
23	W10124350		Not Required Part Or See Note Not Required		Appelez-nous	-
24	53-0198		Support Asm		Appelez-nous	-
25	25-7813		Spacer		Appelez-nous	-
26	53-0642		Cyl Roller		Appelez-nous	-
27	WP25-7854		Ring, Retaining   (Replaces: 25-7854)				$ 10.68
28	25-7814		Washer				$ 5.33

    View Diagram in Separate Window       Print Part List
