02 - Control Panel


03 - Meter Case


04 - Rear Panel


05 - Agitator, Basket And Tub


06 - Brake, Clutch, Gearcase, Motor And Pump


07 - Machine Base


08 - Wiring Harness


09 - Brake And Drive Tube


10 - Gearcase


11 - Water System


12 - Miscellaneous


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
2	3950775		Backer Plate		Appelez-nous	-
2	3361029		(side)				$ 34.04
3	WP90767		Screw, 8a X 3/8   (Replaces: 90767)			Immediately	$ 7.04
5	3950773		Backer Plate		Appelez-nous	-
6	3949737		Cap, End (r.h.)				$ 49.53
8	3949734		Cap, End (l.h.)		Appelez-nous	-
9	3950791		Panel, Control		Appelez-nous	-
10	3348542		Switch, Water Level		Appelez-nous	-
11	3950800		Bracket, Control		Appelez-nous	-
12	3949599		Bezel, Display		Appelez-nous	-
13	3951042		Harness, Console		Appelez-nous	-
14	686770		Protector Support		Appelez-nous	-
15	3407139		Display, Electronic		Appelez-nous	-
16	3407136		Board, Control		Appelez-nous	-
18	WPW10366705		Screw & Washer   (Replaces: 3393909)				$ 6.75
20	WPW10109200		Screw   (Replaces: 97787)			Immediately	$ 7.20
22	W10113937		Clip, Grounding   (Replaces: 357572)				$ 9.75
23	3951035		Switch, Membrane		Appelez-nous	-
26	3950774		Mounting Stud		Appelez-nous	-
34	689559		Nut, Push-in (2)		Appelez-nous	-
