| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | 131168200 | Screw (4) |
|
Immediately | $ 14.18 | ||||
| 2 | 131332700 | Hinge (2) |
|
- | |||||
| 3 | 5303015671 | Screw |
|
- | |||||
| 4 | 131205300 | Screw |
|
Immediately | $ 12.10 | ||||
| 5 | 5303281129 | Cord-service |
|
- | |||||
| 6 | 3281130 | Cover |
|
- | |||||
| 7 | 134154100 | Screw (Replaces: 131301100) |
|
$ 13.46 | |||||
| 9 | 5303015671 | Screw |
|
- | |||||
| 10 | 5303281018 | Plate-cover |
|
- | |||||
| 12 | 131168200 | Screw (4) |
|
Immediately | $ 14.18 | ||||
| 13 | 131825900 | Bearing (included In Rear Bearing Kit.) (Replaces: 5303281008) |
|
Immediately | $ 10.97 | ||||
| 14 | 131724301 | Bracket-bearing (included In Rear Bearing Kit) (Replaces: 5303281023) |
|
Immediately | $ 25.66 | ||||
| 15 | 5303281033 | Screw |
|
- | |||||
| 16 | 5303281119 | Heater Hsg & Seal Assembly |
|
- | |||||
| 17 | 131243700 | Screw (2) (included In Rear Bearing Kit) |
|
$ 3.36 | |||||
| 18 | 5308015399 | Thermostat - Safety |
|
$ 242.18 | |||||
| 19 | 5303931781 | Shaft (included In Rear Bearing Kit) |
|
$ 142.32 | |||||
| 21 | 3201199 | Drum |
|
$ 246.86 | |||||
| 22 | 137552900 | Vane (3) (Replaces: 5303201200) |
|
$ 54.95 | |||||
| 23 | 131205200 | Screw (6) |
|
- | |||||
| 25 | 131378200 | Screw (3) |
|
- | |||||
| 26 | 3281123 | Duct-heat |
|
- | |||||
| 27 | 5303281035 | Screw (3) |
|
- | |||||
| 28 | 3201202 | Grommet (4) |
|
$ 22.47 | |||||
| 29 | 5303281032 | Bolt-foot (4) |
|
- | |||||
| 30 | 5303010202 | Screw (4) |
|
$ 5.15 | |||||
| 31 | 5303281020 | Nut, Flat (included In Rear Bearing Kit.) |
|
$ 17.01 | |||||
| 32 | 5303281019 | Ball (included In Rear Bearing Kit.) |
|
$ 16.30 | |||||
| 35 | 131346400 | Pin, Locating |
|
$ 12.44 | |||||
| 36 | 131353500 | Clip-cab. Front Btm |
|
- | |||||
| *02240 | 5303281153 | Rear Bearing Kit |
|
Immediately | $ 46.64 |
