Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	309458B		End Cap, Lt (blk)		Appelez-nous	-
2	309882B		Spacer, Handle (blk)		Appelez-nous	-
3	309642B		Assy, Glass Heat Shield (blk)		Appelez-nous	-
4	309461B		Bushing, Handle (blk)		Appelez-nous	-
5	309456B		Trim, Upper Door		Appelez-nous	-
6	Y0309973		Screw, No.10-24x11/4 (trs Ph Hd)		Appelez-nous	-
7	314563CG		Liner, Oven Door (elec)		Appelez-nous	-
8	0062614		Insulation,door-sub Backer		Appelez-nous	-
9	Y0300432		Gasket, Oven Dr 82``		Appelez-nous	-
10	314692CG		Oven Door Pad W/o Window		Appelez-nous	-
11	Y0309016		Screw, No.8-18 X 3/8 P Hex Wsh T		Appelez-nous	-
12	Y0302648		Rivet, Pop		Appelez-nous	-
13	Y0309627		Bumper, Rubber		Appelez-nous	-
14	Y0303777		Screw No.8-18 X .375 (bl)		Appelez-nous	-
15	309457B		End Cap, Rt (blk)		Appelez-nous	-
16	309462B		Glass, Outer Door (blk)		Appelez-nous	-
17	309460B		Support, Glass (blk)		Appelez-nous	-
18	309624B		Handle, Oven Door (blk)		Appelez-nous	-
NI	W11245710		Screw, No.8-18 X 3/8 P Trs Hd Lp   (Replaces: Y0041809)			Immediately	$ 12.65
NI	0300584		Label,cleaning Instr.		Appelez-nous	-
NI	Y0314198		Support, Insulation		Appelez-nous	-
