| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 19 | 318244833 | Control Panel,assembly ,w/stainless Trm |
|
$ 819.05 | |||||
| 68 | 318237220 | Housing,top/control |
|
- | |||||
| 69 | 318237320 | Shield,control |
|
- | |||||
| 77 | 318293702 | Spacer,control ,(2) |
|
$ 16.22 | |||||
| 100 | 5303297477 | Screw,6-20 X 1 1/4 |
|
$ 15.17 | |||||
| 77A | 316114100 | Spacer |
|
$ 60.96 | |||||
| F20 | 316576631 | Controller,electronic ,es630 |
|
$ 526.91 | |||||
| F97 | 316443926 | Board,relay ,dual Oven |
|
$ 457.56 | |||||
| F99 | 316535200 | Board,power Supply ,8v ,(2) |
|
$ 408.36 | |||||
| FNI | 318532113 | Harness,wiring ,communication ,13 Connectors |
|
$ 198.70 | |||||
| NI | 131892100 | Screw,control Mtg ,6-32 X .25 ,(5) (Replaces: 316524400) |
|
- | |||||
| NI | 134178901 | Screw,8-18 X 0.500 (Replaces: 5303211311) |
|
$ 14.89 |
