Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	Y0088674		Socket, Oven Light		Appelez-nous	-
2	Y0042175		Bulb, Light		Appelez-nous	-
3	Y0315057		Cage, Oven Light		Appelez-nous	-
4	Y0063532		Broil Element,3000 Watt				$ 66.11
5	WP77001094		Element, Bake (240v-2500w)   (Replaces: Y0059552)			Immediately	$ 39.58
6	WP8203546		Terminal Block   (Replaces: Y0306378)			Immediately	$ 27.12
NI	Y0072270		Screw, Grounding		Appelez-nous	-
NI	WPW10245259		Strap, Ground   (Replaces: Y0306379)			Immediately	$ 31.65
NI	0306381		Hex Nut No.10-32 Nickel		Appelez-nous	-
NI	W10823699		Element, Ribbon (1500 Watts)   (Replaces: Y0314911)			Immediately	$ 145.67
NI	Y0314909		Element, Ribbon (1200 Watts)		Appelez-nous	-
NI	W10823708		Element, Ribbon (2000 Watts)   (Replaces: Y0314912)				$ 307.60

    View Diagram in Separate Window       Print Part List
