| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | 200555 | Agitator | Series 10 |
|
- | ||||
| 2 | 200730 | Agitator Shaft | Series 10 |
|
- | ||||
| 3 | 200739 | Gear Housing | Series 10 |
|
- | ||||
| 4 | 200750 | Gear Case Cover | Series 10 |
|
- | ||||
| 5 | Y00000000 | See Note Not Available | Series 10 |
|
- | ||||
| 6 | 201189 | Lower Transmission Housing | Series 10 |
|
$ 6.18 | ||||
| 7 | 201537 | Seal And Spring | Series 10 |
|
- | ||||
| 8 | 202521 | Mounting Stem | Series 10 |
|
- | ||||
| 9 | 204012 | Mounting Stem Repair Kit | Series 10 |
|
- | ||||
| 10 | 6-2040130 | Tub Bearing Repair Kit (Replaces: 204013) | Series 10 |
|
Immediately | $ 73.68 | |||
| 11 | 210049 | Intermediate Gear | Series 10 |
|
- | ||||
| 12 | 204966 | Gear Kit-bakelite Agitator | Series 10 |
|
- | ||||
| 13 | 214276 | Washer For Gears | Series 10 |
|
- | ||||
| 14 | 210052 | Pitman | Series 10 |
|
- | ||||
| 15 | 210054 | Pinion | Series 10 |
|
- | ||||
| 16 | 210172 | Lock Washer | Series 10 |
|
- | ||||
| 17 | 210179 | Retaining Ring | Series 10 |
|
- | ||||
| 18 | 210183 | Groov-pin, 1/4 X 1-1/4 | Series 10 |
|
- | ||||
| 19 | 210286 | Seal | Series 10 |
|
$ 14.27 | ||||
| 20 | 210315 | Pinion | Series 10 |
|
- | ||||
| 21 | 210454 | Bolt | Series 10 |
|
- | ||||
| 22 | 210610 | Stud For Segment | Series 10 |
|
$ 95.99 | ||||
| 23 | 210611 | Stud-intermediate Gear | Series 10 |
|
$ 118.85 | ||||
| 24 | 210612 | Stud-pitman | Series 10 |
|
- | ||||
| 25 | 210632 | Gasket | Series 10 |
|
- | ||||
| 26 | 210670 | Segment | Series 10 |
|
- | ||||
| 27 | 210690 | Seal, Rubber | Series 10 |
|
$ 13.19 | ||||
| 28 | 211022 | Bearing | Series 10 |
|
- | ||||
| 29 | 211028 | Deflector,water (drive Tube) | Series 10 |
|
- | ||||
| 30 | 211047 | Nut, Clamping (inner Tub) | Series 10 |
|
- | ||||
| 31 | WP211089 | Lug, Stop (Replaces: 211089) | Series 10 |
|
$ 10.16 | ||||
| 32 | WP22003555 | Washer, Lock (Replaces: 211090) | Series 10 |
|
$ 19.26 | ||||
| 33 | 211130 | Liner, Tub Bearing | Series 10 |
|
$ 724.10 | ||||
| 34 | 205811 | Counterweight | Series 10 |
|
- | ||||
| 35 | WP62739 | Nut (Replaces: Y052740) | Series 10 |
|
$ 6.85 | ||||
| 36 | 211210 | Washer,clamping Nut(stainless) | Series 10 |
|
$ 5.84 | ||||
| 37 | 211344 | Bolt, 5/16-18 X 1-1/8 | Series 10 |
|
$ 123.28 | ||||
| 38 | WP912618 | Screw,stop Lug(center Shaft) (Replaces: 211375) | Series 10 |
|
$ 6.98 | ||||
| 39 | WP6-2114830 | Washer, Splined (Replaces: 211483) | Series 10 |
|
$ 7.05 | ||||
| 40 | 211484 | Lug Washer | Series 10 |
|
$ 4.83 | ||||
| 41 | 211485 | Center Shaft | Series 10 |
|
- | ||||
| 42 | 211486 | Screw, 3/8-16 X 1/2 Inch | Series 10 |
|
- | ||||
| 43 | 211487 | Groov-pin | Series 10 |
|
$ 6.64 | ||||
| 44 | 22001423 | Set Screw, Mtg. Stem (Replaces: 211618) | Series 10 |
|
$ 45.54 | ||||
| 45 | 211717 | Wrist Pin | Series 10 |
|
Immediately | $ 76.33 | |||
| 46 | 211837 | Spring For Tub Seal | Series 10 |
|
- | ||||
| 47 | WP6-0A57420 | Seal, Agitator Drive Shaft (Replaces: Y0A4298) | Series 10 |
|
Immediately | $ 33.64 | |||
| 48 | 0A4731 | Spline | Series 10 |
|
- | ||||
| 49 | WP6-0A57420 | Coil Spring-center Seal (Replaces: Y014792) | Series 10 |
|
Immediately | $ 33.64 | |||
| 50 | Y014827 | Washer-center Shaft | Series 10 |
|
- | ||||
| 51 | Y015149 | Brass Washer-agitator Seal | Series 10 |
|
- | ||||
| 52 | Y015494 | Stop Ring-agitator Shaft | Series 10 |
|
- | ||||
| 53 | Y015627 | Screw, Hex Hd Cap 5/16 X 5/8 | Series 10 |
|
$ 8.15 | ||||
| 54 | Y015629 | Bolt, Grinding Chamber-drai | Series 10 |
|
- | ||||
| 55 | 015639 | Dowel Pin | Series 10 |
|
- | ||||
| 56 | WPY015666 | Washer,retaining(center Seal)- (Replaces: Y015666) | Series 10 |
|
$ 6.96 | ||||
| 57 | Y015667 | Retaining Ring | Series 10 |
|
$ 8.70 | ||||
| 58 | Y015902 | Spring For Agitator | Series 10 |
|
- | ||||
| 59 | 052836 | Cap Screw, 3/8-16 X 1 | Series 10 |
|
- | ||||
| 60 | Y053241 | Set Screw, Pulley | Series 10 |
|
- | ||||
| 61 | Y054866 | Lock Washer | Series 10 |
|
- | ||||
| 62 | Y055978 | Rubber Adhesive, 2 Oz Tube | Series 10 |
|
$ 38.40 | ||||
| 63 | WPY055980 | Hi-temp Adhesive, 2 Oz Tube (Replaces: Y055980) | Series 10 |
|
Immediately | $ 28.72 | |||
| 64 | WPY056016 | Center Seal Grease, 4oz Tub (Replaces: Y056016) | Series 10 |
|
$ 14.43 | ||||
| 65 | Y056080 | Trans Lube - Auto, 34 Oz. | Series 10 |
|
- | ||||
| 66 | 038313 | Wrench, Spanner | Series 10 |
|
- |
