| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | 69578-1 | Tunnel, Air | 10 |
|
- | ||||
| 1 | 68418-1 | Seal, Closed Cell | 10 |
|
- | ||||
| 2 | 68289-2 | Insulation, Air Tunnel | 10 |
|
- | ||||
| 3 | 68290-3 | Damper, Air Tunnel | 10 |
|
- | ||||
| 4 | 68282-1 | Bellows, Air Tunnel | 10 |
|
- | ||||
| 5 | W11233072 | Screw (Replaces: 400015-31) | 10 |
|
Immediately | $ 12.62 | |||
| 6 | 60570-36 | Frame, Shelf | 10 |
|
- | ||||
| 7 | 66604-23 | Glass, Cantilever Split Shelf | 10 |
|
- | ||||
| 8 | 60524-6 | Trim, Meat Shelf (front) | 10 |
|
- | ||||
| 9 | 65276-4 | Trim, Meat Shelf (rear) | 10 |
|
- | ||||
| 10 | 60570-45 | Frame, Shelf | 10 |
|
- | ||||
| 11 | 66604-22 | Glass, Cantilever Shelf | 10 |
|
- | ||||
| 12 | 60524-28 | Trim,shelf (full Front) | 10 |
|
- | ||||
| 13 | 65276-21 | Trim, Shelf (full Rear) | 10 |
|
- | ||||
| 14 | 66333-1 | Clip, Shelf Trim | 10 |
|
- | ||||
| 15 | 68238-2 | Rail, Cantilever Shelf | 10 |
|
- | ||||
| 15 | 68238-1 | Rail, Cantilever Shelf | 10 |
|
- | ||||
| 15 | 68238-3 | Rail, Cantilever Shelf | 10 |
|
- | ||||
| 16 | 400037-28 | Screw | 10 |
|
- |
