02 - Chest Freezer Parts
New Model Search:
| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 2 | 5300300173 | External Condenser (not Original Equipment-service Repla |
|
- | |||||
| 3 | 5306593887 | Plug, Drain, Liner |
|
- | |||||
| 4 | 5300128045 | Plug-drain Shell |
|
- | |||||
| 5 | 06594053 | Adapter, Hose |
|
- | |||||
| 6 | 08016808 | Grommet-control Tube |
|
- | |||||
| 7 | 5303210235 | Breaker Ends-gray (2) |
|
- | |||||
| 8 | 5303925095 | Breaker Front-gray |
|
- | |||||
| 9 | 5303925095 | Breaker Rear-gray |
|
- | |||||
| 10 | 5303210238 | Breaker Corners-gray (4) |
|
- | |||||
| 17 | 216034600 | Divider-drain Pan |
|
- | |||||
| 18 | 5306594584 | Support Divider (4) |
|
$ 19.80 | |||||
| 19 | 5308016768 | Basket (2) |
|
- | |||||
| 20 | 5303019003 | Handle Basket-blue (4) |
|
- | |||||
| 29 | 297321900 | Hinge (2) (Replaces: 5303925006) |
|
$ 90.01 | |||||
| 31 | 5309950602 | Screw Hinge Wing (8) |
|
$ 5.30 | |||||
| 32 | 216032201 | Lid Exterior-white |
|
- | |||||
| 33 | 3019005 | Panel Inner Lid-white |
|
- | |||||
| 34 | 3019006 | Light Shield |
|
- | |||||
| 38 | 5309950054 | Handle |
|
- | |||||
| 39 | 5300128795 | Insert Handle |
|
- | |||||
| 40 | 5309948647 | Fastener, Handle |
|
- | |||||
| 42 | 297147700 | Key Lock (Replaces: 5308037402) |
|
Immediately | $ 7.57 | ||||
| 43 | 5303925107 | Lock-complete |
|
- | |||||
| 44 | 5300300791 | Lock Hook |
|
- | |||||
| 46 | 5300128901 | Insulation Lid |
|
- | |||||
| 47 | 3019007 | Gasket Lid-gray |
|
- | |||||
| 48 | 5303212828 | Clip-panel (46) |
|
$ 16.63 | |||||
| 50 | 216040000 | Wire Harness Lid |
|
- | |||||
| 51 | 216858001 | Screw-ground Wire (Replaces: 5303161215) |
|
Immediately | $ 10.85 | ||||
| 52 | 09950610 | Clip |
|
- | |||||
| 53 | 216039700 | Socket-light |
|
- | |||||
| 54 | 5303091423 | Light Bulb |
|
- | |||||
| 55 | 5306599968 | Retainer Socket |
|
- | |||||
| 74 | 216089500 | Wiring Harness |
|
- | |||||
| 75 | 08009412 | Screw |
|
- | |||||
| 76 | 08009412 | Screw |
|
- | |||||
| 77 | 08016762 | Clip Wires (2) |
|
- | |||||
| 79 | 5304496560 | Cold Control (Replaces: 5303212610) |
|
$ 49.62 | |||||
| 80 | 5303305677 | Drier (Replaces: 5308000027) |
|
Immediately | $ 31.67 | ||||
| 81 | 5308008778 | Grommet Compressor (4) |
|
- | |||||
| 83 | 216056400 | Clip Compressor (4) |
|
- | |||||
| 84 | 216022700 | Access Panel-white |
|
- | |||||
| 85 | 216034508 | Control Knob |
|
- | |||||
| 86 | 5303212615 | Support, Compressor (2) |
|
- | |||||
| 87 | 08016776 | Screw-support (2) |
|
- | |||||
| 88 | 5303925125 | Compressor |
|
- | |||||
| 89 | 216008900 | Relay |
|
- | |||||
| 90 | 5303206836 | Overload |
|
- | |||||
| 93 | 215012000 | Clamp, Cover |
|
$ 2.63 | |||||
| 95 | 216858001 | Screw Access Panel (2) (Replaces: 5303161215) |
|
Immediately | $ 10.85 | ||||
| 96 | 08016777 | Retainer-power Cord (not Original Equipment-customer Pur |
|
- | |||||
| 98 | 5303916391 | Run Capacitor |
|
- | |||||
| 100 | 5303208663 | Plug-control Indicator |
|
- | |||||
| 101 | 5303210240 | Latch Catch-gray |
|
- | |||||
| 102 | 5303208481 | Support Latch |
|
- |
