SELECT A DIAGRAM

02 - Backguard


03 - Door Parts


04 - Cooktop Parts


05 - Burner, Manifold And Gas Control


06 - Body Parts


07 - Drawer Parts


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	665T188P02		Spcr Bodyside (8)		Appelez-nous	-
4	662T042P01		Socket-oven Light		Appelez-nous	-
5	374T018P05		Light Bulb, Oven		Appelez-nous	-
6	3204483		Wire, Glass Retainer		Appelez-nous	-
7	5304524341		Glass - Oven Light Lens   (Replaces: 08011086)			Immediately	$ 14.18
8	3131569		Channel Dr. Hinge		Appelez-nous	-
9	3131570		Cover-hinge Cutout (2)				$ 7.35
10	3131312		Shld. Heat (upper)		Appelez-nous	-
11	3131313		Shld Heat Lower		Appelez-nous	-
12	3131295		Clp. Therm. Bulb (2)		Appelez-nous	-
13	3051734		Switch, Latching		Appelez-nous	-
14	241T001P01		Fstnr Push On (3)		Appelez-nous	-
15	174T329P01		Cover, Rod		Appelez-nous	-
16	3203082		Back-main		Appelez-nous	-
17	3051495		Rod, Light		Appelez-nous	-
20	695T128P04		Switch, Door		Appelez-nous	-
21	3131289		Brkt Light Switch		Appelez-nous	-
22	3131590		Shield, Rear Wall		Appelez-nous	-
23	3131316		Shield, Heat		Appelez-nous	-
24	145T130P01		Clip, Wire		Appelez-nous	-
25	3131931		Flue		Appelez-nous	-
26	3131355		Gskt Flue		Appelez-nous	-
27	358T158S02		Knob, Latch		Appelez-nous	-
28	368T027P01		Latch, Door		Appelez-nous	-
29	3131357		Handle, Latch		Appelez-nous	-
30	3131101		Cover, Plate		Appelez-nous	-
31	095T030F02-86		Burner Box		Appelez-nous	-
32	3200835		Shield, Main Front		Appelez-nous	-
33	3131314		Shield-oven-top		Appelez-nous	-
35	3200790		Pnl. B/s-almond-rh		Appelez-nous	-
36	636M004P01		Screw, Leveling		Appelez-nous	-
37	3051221		Rack, Oven (2)		Appelez-nous	-
38	3131356		Insert, Broiler Pan		Appelez-nous	-
39	539T010F01-86		Pan, Broiler		Appelez-nous	-
40	058T036F03-86		Bottom, Oven		Appelez-nous	-
41	102T044P02		Bttn. Remove Sw.		Appelez-nous	-
42	174T333P01		Cover, Burner Box		Appelez-nous	-
43	3051162		Glide-util Drwr			Immediately	$ 8.22
44	316282700		Screw Oven Btm   (Replaces: 3131732)				$ 9.93
*26093	3934056		Anti-tip Brkt		Appelez-nous	-
*26093	3200833		Insulation, Wrap		Appelez-nous	-
*26093	3131956		Spacer, Baffle		Appelez-nous	-
*26093	3200834		Shield - Heat B/s		Appelez-nous	-
14A	3051307		Stud, Spacer (2) (non-illustrated)		Appelez-nous	-
15A	5304534000		Cord, Power (non-illustrated)   (Replaces: 3131425)			Immediately	$ 33.37
26A	3131593		Shield, Bimetal Latch (non-illustrated)		Appelez-nous	-
26B	636T144P01		Screw Latch Knob (non-illustrated)		Appelez-nous	-
27A	3131737		Washer-blk (non-illustrated)				$ 5.59
27B	655T437F01		Shield, Wool (non-illustrated)		Appelez-nous	-
29A	3200846		Fastener-edge Mount (2) (non-illustrated)		Appelez-nous	-
29B	3200834		Shield-heat Bodyside (2) (non-illustrated)		Appelez-nous	-
35A	3200794		Pnl. B/s-wheat-lh		Appelez-nous	-
35A	3200793		Pnl. B/s-almond-lh		Appelez-nous	-
40A	694T092F01		Support-oven Bot (2) (non-illustrated)		Appelez-nous	-
40B	3131903		Bumper				$ 55.36
41A	241T017P255		Fstnr-power Cord (non-illustrated)		Appelez-nous	-
41B	3131303		Insul - Back (non-illustrated)		Appelez-nous	-
41C	3131302		Insul. Frnt. Main (non-illustrated)		Appelez-nous	-
41D	3131304		Insul. Top (non-illustrated)		Appelez-nous	-
41E	655T434F01		Shield-wire (non-illustrated)		Appelez-nous	-
41F	3131305		Insul.-touch (non-illustrated)		Appelez-nous	-
41G	316282700		Screw Ovn. Btm. (2) (non-illustrated)   (Replaces: 3131732)				$ 9.93
41H	657T018P01		Shield-latch Sw. (non-illustrated)		Appelez-nous	-

    View Diagram in Separate Window       Print Part List
