| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 3 | 5304509722 | Trim-shelf,white ,evaporator ,(3) (Replaces: 216847804) |
|
$ 28.20 | |||||
| 4 | 5303305677 | Drier-filter (Replaces: 216634500) |
|
Immediately | $ 31.67 | ||||
| 6 | 297001600 | Support-shelf,front Lh (Replaces: 3091418) |
|
$ 18.08 | |||||
| 7 | 297001500 | Support, Shelf, Front Rh (Replaces: 08037928) |
|
$ 18.08 | |||||
| 11 | 216474600 | Support-rear Shelf |
|
$ 16.55 | |||||
| 12 | 216225700 | Grommet-spacer |
|
$ 7.77 | |||||
| 13 | 216138900 | Screw,hex Sems ,8-18ab X 1.00 ,evap |
|
$ 3.31 | |||||
| 27 | 216498900 | Grommet,compressor (Replaces: 5308002681) |
|
$ 13.01 | |||||
| 30 | 216596800 | Starter/,relay |
|
- | |||||
| 34 | 5306594529 | Sleeve-compressor |
|
$ 10.34 | |||||
| 35 | 5303272328 | Screw, Ind Hex Sems, 1/4, 28 Unfx, Compressor |
|
$ 10.34 | |||||
| 53 | 216347800 | Cover Terminal,cover-comp Term |
|
- | |||||
| 86 | 216036600 | Screw,ph Washer Head ,8-32ca X 0.500 ,thread Forming |
|
- | |||||
| 43A | 216629700 | Clip |
|
- | |||||
| F1 | 5300123788 | Condenser |
|
$ 635.80 | |||||
| F29 | 216888100 | Compressor,w/o Electricals |
|
- | |||||
| F31 | 216954208 | Overload Protector (Replaces: 216100106) |
|
$ 74.42 | |||||
| F36 | 216940100 | Evaporator,tubing Assy,white |
|
$ 142.99 | |||||
| F5 | 216943100 | Harness-main |
|
$ 28.83 |
