Diagram for 02 - Freezer Door Parts
02 - Freezer Door Parts

Diagram for 03 - Refrigerator Door Parts
03 - Refrigerator Door Parts

Diagram for 04 - Cabinet Parts
04 - Cabinet Parts

Diagram for 05 - Shelves And Supports
05 - Shelves And Supports

Diagram for 06 - Refrigerator Control Assembly, Damp
06 - Refrigerator Control Assembly, Damp

Diagram for 07 - Ice Door, Dispenser And Water Tanks
07 - Ice Door, Dispenser And Water Tanks

Diagram for 08 - Ice Dispenser
08 - Ice Dispenser

Diagram for 09 - Ice Maker And Installation Parts
09 - Ice Maker And Installation Parts

Diagram for 10 - System And Automatic Defrost Parts
10 - System And Automatic Defrost Parts


New Model Search:


1-888-572-4577
< Back to Home
Keyword Search:

Diagram # Part Number Description Series Availability Ships Price Add to Cart
1 215846602 Timer-defrost   (Replaces: 5300187484) In-Stock Immediately $ 28.20

2 5303275517 Box-control Appelez-nous -
3 5308000129 Socket-light Special Order $ 62.16

4 5303001179 Bulb, Light Appelez-nous -
6 5304455649 Screw   (Replaces: 5303001259) Special Order $ 17.01

7 5303001260 Screw Special Order $ 6.73

8 5308010380 Knob-temp Control Appelez-nous -
9 5304455649 Screw   (Replaces: 5303001259) Special Order $ 17.01

10 5303274947 Control-temperature Appelez-nous -
11 5303274945 Housing-cap Tube Appelez-nous -
12 5303001276 Ferrule, Inner Appelez-nous -
13 5303001277 Ferrule, Outer Appelez-nous -
14 5303211383 Box-damper Control Appelez-nous -
15 5308000771 Deflector-air Appelez-nous -
16 5300185373 Rivet, Expansion Appelez-nous -
17 5308010379 Knob-damper Control Appelez-nous -
19 5308009987 Label-shield Rh Appelez-nous -
20 5303211408 Light Shield-refr Appelez-nous -
21 5308009988 Label-shield Lh Appelez-nous -
22 5308015585 Light Shield-freezer Appelez-nous -
23 5308015557 Cover - Fan Appelez-nous -
24 5303001179 Bulb, Light Appelez-nous -
25 218906802 Socket, Light   (Replaces: 5308000815) Special Order $ 17.72

26 5308000124 Ring-fan Orifice Special Order $ 53.58

27 5308002748 Screw Appelez-nous -
28 5308000010 Fan In-Stock Immediately $ 49.03

29 5300158289 Motor-blower In-Stock Immediately $ 149.94

30 5308000107 Bracket-connector Special Order $ 33.23

31 5303205119 Bracket-motor Mtg, Rear Appelez-nous -
32 5303205118 Bracket-motor Mtg, Front Appelez-nous -
33 5300157666 Bushing - Motor Mtg, (2) Appelez-nous -
*52733 5303015135 Wiring Harness-main Control Appelez-nous -
25A 08015577 Box - Light Socket (non-illustrated) Appelez-nous -
4A 3001269 Insulator-box Rear (non-illustrated) Appelez-nous -

    View Diagram in Separate Window     Print Icon   Print Part List

Diagram for FPCE22VWPL1
