SELECT A DIAGRAM
02 - Door Parts
03 - Cabinet Parts
04 - Cabinet Parts
05 - Shelves And Supports
06 - System And Automatic Defrost Parts
SELECT A DIAGRAM
New Model Search:
| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | 5303200465 | Mullion, White |
|
- | |||||
| 3 | 215141301 | Washer-mullion Mtg, White |
|
- | |||||
| 3 | 5303206754 | Washer No. 10 Flat, 7/32 X 7/16 Od, Steel |
|
- | |||||
| 3 | 215141311 | Washer-mullion Mtg, Almond |
|
- | |||||
| 4 | 5303200464 | Spacer-mullion Mtg, Steel |
|
- | |||||
| 5 | 5308017408 | Heater-mullion |
|
- | |||||
| 6 | 5308003604 | Strap, Mullion Mtg |
|
- | |||||
| 7 | 3018881 | Top Panel-refr |
|
- | |||||
| 8 | 5303018899 | Divider, Styrofoam |
|
- | |||||
| 9 | 5303001537 | Bottom Panel-frzr |
|
- | |||||
| 10 | 5303001324 | Tray-ice, Plastic, (2) |
|
- | |||||
| 11 | 5303283107 | Shelf-freezer |
|
$ 155.82 | |||||
| 12 | 5308014667 | Deflector-air, W/seal |
|
- | |||||
| 13 | 5303001448 | Cover-air Deflector (non-illustrated) |
|
- | |||||
| 14 | 5309918806 | Switch-light/lamp |
|
Immediately | $ 21.97 | ||||
| 15 | 5303001179 | Light Bulb/lamp,40 W |
|
- | |||||
| 17 | 3018895 | Box, Control |
|
- | |||||
| 18 | 3018893 | Knob, Temp Control |
|
- | |||||
| 19 | 5303018896 | Switch, Energy Saver |
|
- | |||||
| 21 | 5303018894 | Control-temperature |
|
- | |||||
| 22 | 3018891 | Housing, Cont Cap Tube |
|
- | |||||
| 23 | 215846602 | Timer (Replaces: 215267800) |
|
Immediately | $ 28.20 | ||||
| 24 | 215069027 | Frame-meat Kpr Shlf, Cantilever |
|
- | |||||
| 24 | 215069030 | Frame-full Shelf, Cantilever |
|
- | |||||
| 25 | 5349001603 | Cover-crisper Pan |
|
- | |||||
| 26 | 5303299798 | Pan-crisper, Lh |
|
- | |||||
| 26 | 5303299799 | Pan-crisper, Rh |
|
- | |||||
| 27 | 5303205987 | Support-crisper Cvr, Adjustable |
|
$ 48.41 | |||||
| 28 | 3201150 | Cap-protector |
|
$ 4.57 | |||||
| 29 | 5303290028 | Trim-full Shelf, Front |
|
- | |||||
| 31 | 5303290024 | Pan-meat |
|
- | |||||
| 34 | 5303288235 | Container-ice |
|
- | |||||
| 40 | 5303288858 | Glass-shelf, Full Shelf, (2) |
|
- | |||||
| 41 | 5303290027 | Trim-full Shelf, Snap-on, Rear |
|
- | |||||
| 42 | 5303209272 | Hanger-pan/tray, Lh |
|
$ 90.83 | |||||
| 59 | 215115900 | Screw-hinge/mullion, Pan Head, 10-24(23) X 7/8 |
|
- | |||||
| 81 | 5304455650 | Screw (Replaces: 5308016566) |
|
$ 14.18 | |||||
| 123 | 08014528 | Screw-hanger Mtg, Cr Pan Hd Plask, 8 X 1/2, Meat/deli P |
|
$ 4.31 | |||||
| *91871 | 5303211351 | Lock-shelf Trim, Rear |
|
- | |||||
| *91871 | 5300170910 | Clip-cantilevr Shlf |
|
$ 2.60 | |||||
| 12A | 5303001449 | Seal-air Deflector (non-illustrated) |
|
$ 2.12 | |||||
| 13A | 5303200590 | Extension, Air Deflector, With Insulation (non-illustrated) |
|
- | |||||
| 16A | 218906802 | Socket-light/lamp (Replaces: 5308000815) |
|
$ 17.72 | |||||
| 17A | 5308016567 | Nut-anchor (non-illustrated) |
|
- | |||||
| 21A | 5303001260 | Screw |
|
$ 6.73 | |||||
| 23A | 5304455649 | Screw (Replaces: 5303001259) |
|
$ 17.01 | |||||
| 29A | 5303209274 | Retainer-glass (non-illustrated) |
|
- | |||||
| 42A | 5303209273 | Hanger-pan/tray, Rh (non-illustrated) |
|
$ 60.06 | |||||
| 7A | 5303001380 | Screw |
|
- | |||||
| 8A | 3018900 | Harness-wiring, Control/divider (non-illustrated) |
|
- | |||||
| 8B | 3205266 | Protector-edge (non-illustrated) |
|
$ 80.09 |
