| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | 0284291 | Bracket | 1 |
|
- | ||||
| 1 | 0284298 | Bracket | 1 |
|
- | ||||
| 1 | 7412P005-60 | Ballast | 1 |
|
- | ||||
| 1 | 3801F109-34 | (right) | 1 |
|
- | ||||
| 2 | 3801F108-45 | Bracket, Clock Mntg | 1 |
|
- | ||||
| 3 | 7601P047-60 | + Clock | 1 |
|
- | ||||
| 4 | 7724E010 | Cover Bkgd Lamp | 1 |
|
- | ||||
| 4 | 7728P020-60 | Trim, Overlay | 1 |
|
- | ||||
| 5 | 7706P166-60 | Extrusion, Glass Spt | 1 |
|
- | ||||
| 6 | 7706P019-60 | Extrusion, Glass Support | 1 |
|
- | ||||
| 7 | 7902P198-60 | Glass, Backguard | 1 |
|
- | ||||
| 7 | 7720P061-60 | Trim, Glass | 1 |
|
- | ||||
| 8 | 7711P171-60 | Knob, Clock (button-blk) | 1 |
|
$ 19.90 | ||||
| 9 | 7711P172-60 | Knob, Clock (blk) | 1 |
|
$ 23.55 | ||||
| 10 | 7711P348-60 | Knob, Thermostat | 1 |
|
- | ||||
| 10 | 7711P346-60 | Knob, Infinite | 1 |
|
- | ||||
| 10 | 7737P008-60 | Knob, Switch | 1 |
|
- | ||||
| 10 | 7711P347-60 | Knob, Selector | 1 |
|
- | ||||
| 11 | WP95292 | Light, Control Panel (Replaces: 7407P004-60) | 1 |
|
Immediately | $ 121.45 | |||
| 11 | 7407P022-60 | Light, Signal | 1 |
|
- | ||||
| 12 | 1555247 | Grip Nut | 1 |
|
- | ||||
| 13 | 2620W031-00 | Panel, Bkgd Lower | 1 |
|
- | ||||
| 14 | 0719269 | Plate | 1 |
|
- | ||||
| 14 | 0719268 | Plate | 1 |
|
- | ||||
| 15 | 3605F098-20 | Plate, Clock Mntg | 1 |
|
- | ||||
| 16 | W10124350 | Not Required Part Or See Note | 1-34 |
|
- | ||||
| 16 | 7212P032-60 | Seal, Cover | 35 |
|
- | ||||
| 16 | 1448213 | Receptacle, Lamp | 1 |
|
- | ||||
| 17 | 7214P001-60 | Sleeve, Switch | 1 |
|
- | ||||
| 18 | 0862418 | Support | 1 |
|
- | ||||
| 19 | 12001655 | Switch, Fluor (Replaces: 7403P009-60) | 1 |
|
Immediately | $ 41.01 | |||
| 19 | 7403P019-60 | Switch, Light | 1 |
|
- | ||||
| 20 | 7403P023-60 | Switch, Selector | 1 |
|
- | ||||
| 21 | W11122008 | Switch, Inf. Control (Replaces: 7403P069-60) | 1 |
|
$ 143.28 | ||||
| 21 | 7403P101-60 | Switch, Automatic | 1 |
|
- | ||||
| 22 | 7404P034-60 | Thermostat | 1 |
|
- | ||||
| 23 | 7726P018-60 | Trim, Bkgd. (rt) | 1 |
|
- | ||||
| 23 | 7726P007-60 | Trim | 1 |
|
- |
