| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | DE60-60025A | Pin, Foot |
|
$ 0.85 | |||||
| 2 | DE61-40065A | Leg |
|
$ 17.58 | |||||
| 3 | DE26-00123A | Transformer |
|
$ 144.00 | |||||
| 4 | DE80-10032P | Assy, Base Plate |
|
- | |||||
| 5 | DE31-10171C | Convection, Motor |
|
- | |||||
| 6 | DE31-90019B | Blade-fan |
|
- | |||||
| 7 | DE39-30153B | Wire, Lead |
|
- | |||||
| 8 | DE47-70077C | Heater |
|
- | |||||
| 9 | DE60-30016B | Flange, Nut |
|
$ 0.85 | |||||
| 10 | DE60-40014B | Washer, Motor |
|
$ 3.23 | |||||
| 11 | DE72-30016B | Bush-motor |
|
- | |||||
| 12 | W10284499 | Assembly, Cover |
|
- |
