SELECT A DIAGRAM

01 - Freezer Compartment (b/m Dj31a)


02 - Freezer Door (b/m Dj31a)


03 - Fresh Food Compartment (b/m Dj31a)


04 - Fresh Food Door (b/m Dj31a)


05 - Optional Ice Maker (b/m Dj32a)


06 - Shelves & Accessories (b/m Dj31a)


07 - Unit Compartment & System (b/m Dj31a)


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	60096-9		Rail, Shelf Support (center)	10	Appelez-nous	-
1	60096-8		Rail, Shelf Support (rt)	10	Appelez-nous	-
2	400037-28		Screw	10	Appelez-nous	-
3	60340-1		End Cap, Center Rail	10	Appelez-nous	-
4	60524-6		Trim, Meat Shelf (front)	10	Appelez-nous	-
5	65276-4		Trim, Meat Shelf (rear)	10	Appelez-nous	-
6	60570-36		Frame, Shelf	10	Appelez-nous	-
7	66637-47		Pan, Meat	10	Appelez-nous	-
8	60132-96		Handle, Meat Pan	10	Appelez-nous	-
9	60570-46		Frame, Shelf	10	Appelez-nous	-
10	60524-21		Trim, Full Shelf (front)	10	Appelez-nous	-
11	60570-49		Frame, Shelf	10	Appelez-nous	-
12	60524-30		Trim, Split Shelf (front)	10	Appelez-nous	-
13	66644-3		Shelf, Crisper	10	Appelez-nous	-
14	60454-9		Trim, Crisper Shelf	10	Appelez-nous	-
15	12001957		Support, Crisper Shelf   (Replaces: 66105-4)	10			$ 3.35
16	68221-644		Pan, Crisper	10	Appelez-nous	-
17	60132-94		Trim, Crisper Pan	10	Appelez-nous	-
18	60148-4		Seal, Crisper Shelf	10	Appelez-nous	-
19	69570-1		Tunnel, Air (meat)	10	Appelez-nous	-
20	W11233072		Screw   (Replaces: 400015-31)	10		Immediately	$ 12.62
21	66814-3		Rail, Meat Pan (right)	10	Appelez-nous	-
22	66813-3		Rail, Meat Pan (left)	10	Appelez-nous	-
23	65276-2		Trim, Split Shelf (rear)	10	Appelez-nous	-
24	65276-34		Trim, Full Shelf (rear)	10	Appelez-nous	-
25	66333-1		Clip, Shelf Trim	10	Appelez-nous	-
26	68139-18		Glass, Full Shelf	10	Appelez-nous	-
27	68139-20		Glass, Split Shelf	10	Appelez-nous	-
28	68139-21		Glass, Meat Shelf	10	Appelez-nous	-

    View Diagram in Separate Window       Print Part List
