SELECT A DIAGRAM

02 - Cabinet Parts


03 - Electrical Parts


04 - Air Handling Parts


05 - Unit Parts


06 - Compressor Parts


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	3015296		Bulkhead - Control		Appelez-nous	-
2	5303015316		Panel-control		Appelez-nous	-
3	5303015319		Control Temp		Appelez-nous	-
4	5303007754		Screw-control Switch		Appelez-nous	-
5	5308009156		Screw-motor		Appelez-nous	-
6	5303017345		Harness-wire		Appelez-nous	-
7	3015321		Divider - Vertical		Appelez-nous	-
8	3015425		Insulation - Vertical Divider		Appelez-nous	-
9	5303015427		Screw - Divider		Appelez-nous	-
10	5303017914		Clip-sensor Bulb		Appelez-nous	-
11	5303015427		Screw-control Panel		Appelez-nous	-
12	5303270109		Cord-service		Appelez-nous	-
13	5303019026		Capacitor 40-10/370		Appelez-nous	-
14	5303015323		Strap		Appelez-nous	-
15	5303015427		Screw-strap		Appelez-nous	-
16	5303281923		Motor-drive		Appelez-nous	-
17	320118		Switch-slide		Appelez-nous	-
18	5303207304		Spacer Slide Switch		Appelez-nous	-
19	3017344		Switch - Selector				$ 166.42
20	5303015428		Insulation		Appelez-nous	-
21	5303015297		Vent Door		Appelez-nous	-
22	5303015298		Cable		Appelez-nous	-
23	5303202999		Retainer		Appelez-nous	-
24	5303015299		Arm		Appelez-nous	-

    View Diagram in Separate Window       Print Part List
