11 - Gas Valve


12 - Lid Lock


13 - Motor


14 - Motor Assembly


15 - Transmission


16 - Tub


17 - Tub Cover


18 - Tumbler


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	306184		Plug, Blocking (lpg Regulator)	A0	Appelez-nous	-
2	311640		Orifice For Main Burner	A0	Appelez-nous	-
3	306205		Conversion Kit-nat. To Lpg	A0			$ 68.15
4	WP694424		Leak Limiter (lpg)   (Replaces: 314602)	A0			$ 31.11
5	314603		Main Burner Orifice-nat	A0	Appelez-nous	-
6	306206		Conversion Kit-lpg To Nat.	A0	Appelez-nous	-
7	WP90767		Screw   (Replaces: 211294)	A0		Immediately	$ 7.04
8	Y303369		Inlet Duct Assembly (dg)	A0	Appelez-nous	-
9	Y312890		Retainer, Heater Chamber	A0	Appelez-nous	-
10	WP303395		Thermostat, Hi-limit (gas)   (Replaces: 303395)	A0		Immediately	$ 66.35
11	Y303368		Cone, Combustion	A0	Appelez-nous	-
12	WP338906		Sensor, Radiant   (Replaces: Y303377)	A0		Immediately	$ 46.72
13	314509		Combustion Cone Extension	A0	Appelez-nous	-
14	58804A		Coil, Holding & Booster   (Replaces: 306106)	A0		Immediately	$ 28.02
15	279834		Coil, Secondary   (Replaces: 306105)	A0		Immediately	$ 29.57
16	306084		Valve, Gas	A0	Appelez-nous	-
17	311641		Orifice For Main Burner	A0	Appelez-nous	-
17	314603		Main Burner Orifice-nat	A0	Appelez-nous	-
17	311640		Orifice For Main Burner	A0	Appelez-nous	-
18	314508		Bracket For Gas Valve	A0	Appelez-nous	-
19	306162		Burner Assembly With Screw	A0	Appelez-nous	-
20	WP90767		Screw-gas Valve To Bracket   (Replaces: 314568)	A0		Immediately	$ 7.04
21	304971		Screw	A0	Appelez-nous	-
22	4391996		Igniter Assy, Gas Valve   (Replaces: 304970)	A0		Immediately	$ 42.36
23	WP90767		Screw   (Replaces: 212276)	A0		Immediately	$ 7.04
24	WP90767		Screw   (Replaces: 314082)	A0		Immediately	$ 7.04
25	Y313262		Retainer, Wire Harness	A0	Appelez-nous	-
26	310454		Manifold, 2 Inch	A0	Appelez-nous	-
27	306086		Angle Shut Off For Gas Valv	A0	Appelez-nous	-
28	306090		Wire Harness For Gas Valve	A0			$ 36.71
