13 - Gas Valve


14 - Motor & Idler


15 - Top Cover


16 - Transmission


17 - Tub


18 - Tumbler (front & Back)


19 - Tumbler (lse9900acl,acw,adl,adw)


20 - Tumbler (lse9900ael,aew)


21 - Tumbler (lsg9900aal,aaw,abl,abw)


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	306184		Plug, Blocking (lpg Regulator)	A0	Appelez-nous	-
2	311640		Orifice For Main Burner	A0	Appelez-nous	-
3	306205		Conversion Kit-nat. To Lpg	A0			$ 68.15
4	WP694424		Leak Limiter (lpg)   (Replaces: 314602)	A0			$ 31.11
5	314603		Main Burner Orifice-nat	A0	Appelez-nous	-
6	306206		Conversion Kit-lpg To Nat.	A0	Appelez-nous	-
7	Y303369		Inlet Duct Assembly (dg)	A0	Appelez-nous	-
7	WP90767		Screw   (Replaces: 211294)	A0		Immediately	$ 7.04
8	WP90767		Screw   (Replaces: 211294)	A0		Immediately	$ 7.04
8	314509		Combustion Cone Extension	A0	Appelez-nous	-
9	WP338906		Sensor, Radiant   (Replaces: Y303377)	A0		Immediately	$ 46.72
9	WP90767		Screw   (Replaces: 211294)	A0		Immediately	$ 7.04
10	Y303368		Cone, Combustion	A0	Appelez-nous	-
10	WP90767		Screw   (Replaces: 211294)	A0		Immediately	$ 7.04
11	WP90767		Screw   (Replaces: 211294)	A0		Immediately	$ 7.04
11	WP303395		Thermostat, Hi-limit (gas)   (Replaces: 303395)	A0		Immediately	$ 66.35
12	WP90767		Screw   (Replaces: 211294)	A0		Immediately	$ 7.04
12	Y312890		Retainer, Heater Chamber	A0	Appelez-nous	-
13	58804A		Coil, Holding & Booster   (Replaces: 306106)	A0		Immediately	$ 28.02
14	279834		Coil, Secondary   (Replaces: 306105)	A0		Immediately	$ 29.57
15	306084		Valve, Gas	A0	Appelez-nous	-
15	WP90767		Screw   (Replaces: 314082)	A0		Immediately	$ 7.04
16	314508		Bracket For Gas Valve	A0	Appelez-nous	-
17	306162		Burner Assembly With Screw	A0	Appelez-nous	-
17	WP3177991		Screw   (Replaces: Y251119)	A0		Immediately	$ 6.47
18	4391996		Igniter Assy, Gas Valve   (Replaces: 304970)	A0		Immediately	$ 42.36
18	304971		Screw	A0	Appelez-nous	-
19	Y313262		Retainer, Wire Harness	A0	Appelez-nous	-
20	310454		Manifold, 2 Inch	A0	Appelez-nous	-
21	306086		Angle Shut Off For Gas Valv	A0	Appelez-nous	-
22	306090		Wire Harness For Gas Valve	A0			$ 36.71
