| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 51 | 5308037644 | Grommet-door |
|
- | |||||
| 53 | 5303269832 | Duct-air |
|
- | |||||
| 54 | 5303269833 | Duct-air, Fan |
|
- | |||||
| 55 | 5303269834 | Fan Blade |
|
- | |||||
| 56 | 5303269846 | Rivet, Plastic, Fan Air Duct, (2) |
|
- | |||||
| 59 | 5303286094 | Duct-magnetron |
|
- | |||||
| 60 | 5303283612 | Bracket, Angle, Front Right Btm |
|
- | |||||
| *73980 | 5303017863 | Screw, Cr Truss Head, 6-18(a) X 1/2, Angle Bracket, (2) |
|
- | |||||
| *73980 | 317000401 | Harness-wiring, Main, 1.3 Tc, 1000 W, 120 V |
|
- |
