| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | 5303200951 | Liner, Door |
|
- | |||||
| 2 | 5301317933 | Panel (wheat) |
|
- | |||||
| 3 | 5303051630 | Insulation |
|
- | |||||
| 4 | 5308014202 | Handle |
|
- | |||||
| 5 | 5308003153 | Spacer (2) |
|
- | |||||
| 6 | K005109202 | Counter Balance (2) |
|
- | |||||
| 7 | 5308003268 | Seal |
|
- | |||||
| 8 | K1309666 | Clip-seal (10) |
|
- | |||||
| 9 | 5303051822 | Channel-hinge (2) |
|
- | |||||
| 10 | 08003264 | Spring-oven Door |
|
- | |||||
| 11 | 5303931006 | Roller-kit |
|
- | |||||
| 12 | 5303051567 | Rivet (2) |
|
- | |||||
| 13 | 5308012004 | Stud (2) |
|
$ 8.29 | |||||
| 14 | 5308003183 | Hinge, Arm (2) |
|
$ 90.35 |
