| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 38 | 3206100 | Bracket-upper Hinge |
|
- | |||||
| 39 | 5303001037 | Shim - Upper Hinge |
|
$ 12.39 | |||||
| 40 | 3206101 | Cover-upper Hinge, White |
|
$ 49.25 | |||||
| 42 | 3206143 | Screw-lwr Hinge Mtg, Hex Washer Hd, 1/4-20 X 5/8, (4) |
|
- | |||||
| 45 | 5304455651 | Screw (Replaces: 5303001343) |
|
$ 14.41 | |||||
| 56 | 5303001321 | Pin-lower Hinge |
|
$ 17.25 | |||||
| 58 | 5308002748 | Screw |
|
- | |||||
| 59 | 3206134 | Screw-hinge/mullion, Acorn Hx Wsh Hd, 10-24(23) X 1 |
|
- | |||||
| 78 | 5303210353 | Screw, Connectr Brkt, Hex Washer Head, 8, 32(ca) X 1/2 |
|
- | |||||
| 81 | 5304455650 | Screw (Replaces: 5308016566) |
|
$ 14.18 | |||||
| 83 | 5308000107 | Bracket-connector |
|
$ 33.23 | |||||
| *56443 | 5308016571 | Plug-button, Liner |
|
$ 4.79 | |||||
| *56444 | 5303210622 | Pad-rear Base |
|
- | |||||
| 38A | 241710601 | Screw (Replaces: 5303001479) |
|
$ 13.46 | |||||
| 38B | 5308012296 | Tapping Plate, Upper Hinge, (2) (non-illustrated) |
|
$ 47.44 |
