SELECT A DIAGRAM

01 - Cabinet


02 - Electrical Components


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
53	B5635606		Indicator, Zero To 6 Minutes		Appelez-nous	-
54	B5631001		Start Button		Appelez-nous	-
55	C3594901		Nameplate		Appelez-nous	-
56	B5604701		Insert- K		Appelez-nous	-
57	B5631002		Stop Button		Appelez-nous	-
58	B5631003		Light Button		Appelez-nous	-
59	D7027701		Control Panel, Escutcheon		Appelez-nous	-
60	B5635901		Front Panel		Appelez-nous	-
61	M0282005		Nut K				$ 7.07
62	C3626901		Bracket,switch		Appelez-nous	-
63	M0256821		Sems Fastner		Appelez-nous	-
64	M0228015		Screw		Appelez-nous	-
65	B5603103		Socket K		Appelez-nous	-
66	M0360002		Bulb Use M3600-3 K		Appelez-nous	-
67	WPW10068250		Screw   (Replaces: M0202530)				$ 3.66
68	B5631101		Cam,switch		Appelez-nous	-
69	A3134301		Bearing Insert		Appelez-nous	-
70	A3127701		Cam		Appelez-nous	-
71	A3109101		Washer		Appelez-nous	-
72	C3609101		Fan Blade, Stirrer		Appelez-nous	-
73	A3162503		Switch, Interlock, Left Hand		Appelez-nous	-
76	M0211730		Screw		Appelez-nous	-
77	B5602804		Motor 50 Cy		Appelez-nous	-
78	M0306401		Motor		Appelez-nous	-
79	B0591901		Motor Mount		Appelez-nous	-
80	A4568702		Grommet		Appelez-nous	-
81	B5602201		Blower Wheel		Appelez-nous	-
82	A3030302		Gasket		Appelez-nous	-
83	C3595901		Blower Housing		Appelez-nous	-
84	M0216517		Screw		Appelez-nous	-
85	B5607001		Terminal Board		Appelez-nous	-
86	B5601701		Bulkhead		Appelez-nous	-
88	M0102310		Clamp, Wiring		Appelez-nous	-
88	M0102402		Clamp, Power Cord To Bulkhead		Appelez-nous	-
89	WP489464		Screw   (Replaces: M0211217)			Immediately	$ 7.05
90	YA0381501		Clip, Waterline		Appelez-nous	-
91	M0219018		Screw		Appelez-nous	-
92	A3079005		Light Bulb Q (25w/230v)		Appelez-nous	-
93	A3091002		Socket		Appelez-nous	-
94	M0288302		Speed Nut		Appelez-nous	-
95	M0370001		Strain Relief		Appelez-nous	-
96	B5621901		Washer		Appelez-nous	-
97	M0115802		Clip		Appelez-nous	-
97	M0370402		Thermal Prot		Appelez-nous	-
98	B5602303		Power Cord		Appelez-nous	-
99	M0371101		Magnetron		Appelez-nous	-
100	C3596101		Support		Appelez-nous	-
102	M0274028		Washer		Appelez-nous	-
103	M0370601		Coil Magnet		Appelez-nous	-
104	B5643402		Housing		Appelez-nous	-
104	M0250630		Screw K		Appelez-nous	-
105	A0077401		Filter Box Assy K		Appelez-nous	-
106	A3148801		Capacitor K		Appelez-nous	-
107	M0204642		Screw		Appelez-nous	-
108	M0272605		Washer		Appelez-nous	-
109	A3148701		Gasket		Appelez-nous	-
110	B8647901		Capacitor Cover		Appelez-nous	-
111	A3145401		Bale Strap K		Appelez-nous	-
112	A0323801		Terminal Adapter		Appelez-nous	-
114	M0305006		Resistor		Appelez-nous	-
115	M0305005		Resistor		Appelez-nous	-
116	M0274024		Washer K		Appelez-nous	-
117	M0281209		Nut, 10-24 Hex Keps		Appelez-nous	-
118	M0300201		Capacitor		Appelez-nous	-
120	A3149001		Clamp		Appelez-nous	-
121	M0211020		Screw		Appelez-nous	-
122	M0288502		Speed Nut		Appelez-nous	-
122	C3635201		Transformer		Appelez-nous	-
123	M0340101		Switch		Appelez-nous	-
124	M0272511		Washer		Appelez-nous	-
125	M0281401		Nut A		Appelez-nous	-
127	A3141503		Start Switch, Preform		Appelez-nous	-
128	B5631603		Timer, 6 Minute		Appelez-nous	-
129	B5630903		Timer, 36 Minutes		Appelez-nous	-
130	C3627001		Wiring Harness		Appelez-nous	-
131	M0286103		Nut		Appelez-nous	-
132	B5644101		Terminal Board		Appelez-nous	-
133	A3092201		Bracket		Appelez-nous	-
133	A3092202		Bracket		Appelez-nous	-
137	M0256821		Sems Fastner		Appelez-nous	-
138	M0370201		Bridge Rectifier		Appelez-nous	-
139	M0202514		Screw		Appelez-nous	-
140	M0211517		Screw		Appelez-nous	-
141	M0201552		Screw		Appelez-nous	-
142	M0270504		Washer		Appelez-nous	-
143	B5656001		Shield Hv K		Appelez-nous	-
144	B5655901		Clip K		Appelez-nous	-
145	WP489464		Screw   (Replaces: M0211217)			Immediately	$ 7.05
149	A4617502		Wire Nut K		Appelez-nous	-
150	A3073020		Insulation		Appelez-nous	-
151	A3073021		Insulation, Fiberglass		Appelez-nous	-
NI	A0077501		Kit,filter Box Repl		Appelez-nous	-

    View Diagram in Separate Window       Print Part List
