Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	216195900		Evaporator				$ 246.91
2	06599544		Support, Evaporator		Appelez-nous	-
3	06599547		Spacer		Appelez-nous	-
4	5303272332		Heat Exchanger		Appelez-nous	-
6	5303208489		Sleeve-evap Tubing		Appelez-nous	-
7	08013207		Bracket Fan Motor				$ 12.92
8	3205519		Fan Motor		Appelez-nous	-
10	301036		Screw   (Replaces: 3017666)				$ 15.90
14	3205520		Fan Blade		Appelez-nous	-
26	5303305677		Drier-filter   (Replaces: 5308000027)			Immediately	$ 31.67
31	09948773		Insulation				$ 12.60
42	216036600		Screw, Bracket		Appelez-nous	-
43	5300095480		Washer Bracket		Appelez-nous	-
44	05878562		Clamp		Appelez-nous	-
45	06594601		Bracket, Control				$ 17.64
47	5300052943		Screw, Clamp				$ 5.30
48	5308037932		Sleeve, Capillary Tube		Appelez-nous	-
49	216254500		Switch-termination				$ 91.67
50	216254600		Heater-defrost				$ 259.53
51	06599536		Clip, Heater		Appelez-nous	-
52	5308037967		Timer, Defrost		Appelez-nous	-
53	08016580		Bracket		Appelez-nous	-
54	08037849		Screw				$ 8.98
57	05878556		Clip, Compressor Wire		Appelez-nous	-
61	06599531		Air Seal, Rh		Appelez-nous	-
62	3200707		Air Seal, Lh		Appelez-nous	-
63	06594629		Grommet		Appelez-nous	-
69	5303302761		Clamp Harness		Appelez-nous	-
70	09950853		Screw, Knob		Appelez-nous	-
74	5300083897		Condenser				$ 538.37
82	216221901		Thermostat,refrig.temp		Appelez-nous	-
83	216230300		Cover, Control				$ 49.88
84	216008801		Knob-control		Appelez-nous	-
85	216110300		Compressor		Appelez-nous	-
86	216110400		Overload		Appelez-nous	-
87	216008900		Relay		Appelez-nous	-
88	5304464438		Run Capacitor   (Replaces: 216236200)			Immediately	$ 35.38
89	215012000		Clip				$ 2.63
91	216498900		Grommet Compressor (4)   (Replaces: 5308002681)				$ 13.01
92	5306594529		Sleeve Compressor (3)				$ 10.34
93	5303272328		Screw-compressor (3)				$ 10.34
94	216267400		Harness		Appelez-nous	-
100	5303272330		Guard-harness		Appelez-nous	-
	06594651		Wire, Ground		Appelez-nous	-
