Diagram # Part Number Description Series Availability Ships Price Add to Cart
1 35-0235 Spring, Motor Pivot K Appelez-nous -
2 35-2030 Motor K Appelez-nous -
2 LA-2002 Motor Kit K Appelez-nous -
3 33-9945 Slide, Foot K Appelez-nous -
4 WP308544 Screw Purchase   (Replaces: 25-7418) K In-Stock Immediately $ 6.98

5 25-7833 Screw K Appelez-nous -
6 25-7834 Washer K Appelez-nous -
7 33-9946 Isolator, Motor K Special Order $ 32.40

8 33-9944 Washer K Appelez-nous -
9 25-3083 Screw K Appelez-nous -
10 33-9947 Dbl.pivot Slide K Appelez-nous -
11 35-2810 Plate, Motor K Appelez-nous -
12 WP35-3646 Isolator, Motor Plate   (Replaces: 33-9941) K Special Order $ 6.69

13 25-7831 Spacer K Special Order $ 8.04

14 W10143344 Pulley, Motor (60hz)   (Replaces: 35-2124) K Special Order $ 112.73

15 25-7117 Set Screw K Appelez-nous -
16 33-9943 Motor Slide K Appelez-nous -
17 33-9967 Washer, Motor Isolator K Special Order $ 5.27

18 25-7047 Washer, Flat K Special Order $ 30.39

19 WPY707702 Nut, Motor Plate Asy To Motor   (Replaces: 25-7325) K In-Stock Immediately $ 6.26

20 35-2015 Suspension Housing K Appelez-nous -
21 35-2531 Brace, Tub K Appelez-nous -
21 25-7930 Screw 5/16-18x3/4 K Appelez-nous -
22 35-2682 Hook Suspension Spring K Appelez-nous -
22 35-2681 Spring, Suspension K Appelez-nous -
23 35-2025 Plate, Reinforcement K Appelez-nous -
24 25-7912 Screw K Appelez-nous -
25 25-7365 Eye Bolt K Appelez-nous -
26 35-2017 Retainer, Brake Spring K Special Order $ 5.85

27 25-7895 Screw, Susp Hsg To Lwr Brg Asy K Appelez-nous -
28 35-2112 Spring, Brake K Appelez-nous -
29 35-2113 Brake Roter & Lining Assy K Appelez-nous -
30 35-2018 Stator, Brake K Appelez-nous -
31 25-7359 Screw K Appelez-nous -
32 12002213 Spacer-bearing   (Replaces: 35-2016) K In-Stock Immediately $ 98.84

33 25-7909 Washer K Appelez-nous -
34 12002213 Washer   (Replaces: 35-2318) K In-Stock Immediately $ 98.84

35 12002213 Thrust Bearing   (Replaces: 35-2078) K In-Stock Immediately $ 98.84

36 35-2081 Washer K Appelez-nous -
37 12002213 Drive Pulley   (Replaces: 35-2683) K In-Stock Immediately $ 98.84

38 12002213 Upper Cam   (Replaces: 35-2441) K In-Stock Immediately $ 98.84

39 12002213 Cam, Lower   (Replaces: 35-2439) K In-Stock Immediately $ 98.84

40 35-2082 Washer,1.25odx.530idx.062 K Special Order $ 5.61

41 WP25-7854 Ring, Retaining   (Replaces: 25-7854) K Special Order $ 10.68

42 35-2049 Bar, Stabilizer (with Guide) K Appelez-nous -
43 35-2046 Bracket, Stabilizer K Special Order $ 39.94

44 35-2052 Pin, Stabilizer K Special Order $ 6.02

45 35-2039 Pad, Foot K Appelez-nous -
45 WP22004469 Foot, Self Stabilizer   (Replaces: 35-2050) K Special Order $ 14.52

46 35-2007 Cap, Dust K Appelez-nous -
47 WP489483 Screw, No.10 Torq Limiting   (Replaces: 25-7828) K Special Order $ 9.78

48 35-2815 Base, Washer L Appelez-nous -
48 35-2019 Base, Washer K Appelez-nous -
49 25-7838 Speednut K Appelez-nous -
50 25-7915 Hex Nut K Appelez-nous -
51 35-0772 Foot, Front K Appelez-nous -
51 35-0837 Pad, Front Foot K Appelez-nous -
52 WP21002026 Snubber   (Replaces: 35-2357) K In-Stock Immediately $ 9.68

53 WP21352320 Belt, Drive Pulley   (Replaces: 35-2320) K In-Stock Immediately $ 19.29

54 25-0226 Hex Nut K Appelez-nous -
55 25-7830 Spacer K Special Order $ 8.39

56 25-7413 Flat Washer K Appelez-nous -
56 33-9765 Switch, Motor K Appelez-nous -
57 35-2065 Pad, Motor Plate K Appelez-nous -
58 35-2329 Reinf Tub Support K Appelez-nous -
59 25-7910 Screw K Appelez-nous -
60 25-7037 Keps Nut K Appelez-nous -

    View Diagram in Separate Window     Print Icon   Print Part List

Diagram for W20HA3
