01 - Console


02 - Cabinet


03 - Door


04 - Tub , Lit/optional


05 - Dishrack


06 - Pump And Motor


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	300754		Bracket, Control		Appelez-nous	-
2	301638		Console Assembly		Appelez-nous	-
3	301062		Motor, Timer		Appelez-nous	-
4	300516		Relay, Start (alternate)		Appelez-nous	-
4	301620		Relay, Start (alternate)		Appelez-nous	-
4	301536		Relay, Start (alternate)		Appelez-nous	-
5	339494		Screw		Appelez-nous	-
6	302588		Timer		Appelez-nous	-
7	WP487353		Screw, 6-20 X .38   (Replaces: 301502)				$ 6.81
9	WP488627		Screw, 8-32 X 1/2   (Replaces: 300128)				$ 6.81
10	302162		Retainer, Harness		Appelez-nous	-
11	302076		Switch, Pushbutton		Appelez-nous	-
12	301977		Button (6)		Appelez-nous	-
13	300242		Barrier, Pushbutton Switch		Appelez-nous	-
14	W11693756		Screw, 8-18 X 5/8   (Replaces: 688983)			Immediately	$ 12.65
20	WP94614		Terminal (female)   (Replaces: 94614)				$ 6.90
21	162400		Screw		Appelez-nous	-
23	302142		Insert		Appelez-nous	-
25	WP489128		Screw,   (Replaces: 98209)				$ 9.79
26	719585		Connector, Terminal (motor)		Appelez-nous	-
28	300996		Dial, Indicator		Appelez-nous	-
29	94613		Terminal, (male)		Appelez-nous	-
30	301010		Knob, Timer		Appelez-nous	-
31	353425		Receptacle (wetting Agent Dispenser)		Appelez-nous	-
34	301624		Trim, Console		Appelez-nous	-
36	353424		Plug, Terminal (wetting Agent Dispenser)				$ 18.95

    View Diagram in Separate Window       Print Part List
