| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | 808676601 | Cap, Low Profile, Agitator |
|
$ 36.34 | |||||
| 3 | 5304500572 | Screw, M6x28 With Nut |
|
Immediately | $ 21.92 | ||||
| 4 | 808726001 | Agitator, Low Profile |
|
Immediately | $ 104.83 | ||||
| 5 | 5304501142 | Motor, W/gearbox Asmy |
|
Immediately | $ 495.16 | ||||
| 6 | 140236745018 | Actuator, Motor Brake, Clutch (Replaces: 5304492254) |
|
Immediately | $ 33.62 | ||||
| 7 | 5304536279 | Suspension, Asmy (Replaces: 5304500464) |
|
Immediately | $ 39.65 | ||||
| 8 | 5304500580 | Suspension, Cap Top, Top |
|
Immediately | $ 19.90 | ||||
| 9 | 5304520189 | Tub, Outer Asmy (Replaces: 5304500417) |
|
$ 347.00 | |||||
| 10 | 5304500426 | Hub, Tub Support |
|
Immediately | $ 185.60 | ||||
| 13 | 5304500577 | Screw-m8x1, 25x25 Brass, M8x1, 25x25, Brass |
|
- | |||||
| 15 | 809088900 | Ring, Balance Asmy |
|
$ 201.71 | |||||
| 16 | 809090501 | Cover, Outer Tub |
|
$ 128.62 | |||||
| 17 | 5304500519 | Barrier, Motor, Cover |
|
$ 40.59 | |||||
| 18 | 5304492298 | Screw, M4x8, Machine Truss |
|
$ 7.40 | |||||
| 19 | 5304500573 | Screw, 4x28, Pf, Cab, Sext, Plast |
|
- | |||||
| 20 | 5304500427 | Tub, Spin Asmy, Pele |
|
$ 399.74 | |||||
| 22 | 5304504885 | Sensor, Pressure (Replaces: 5304500461) |
|
Immediately | $ 54.26 | ||||
| 24 | 5304518458 | Hose, Drain (Replaces: 5304500511) |
|
Immediately | $ 58.25 | ||||
| 25 | 5304536804 | Clamp, Hose, Wire (Replaces: 131306229) |
|
$ 5.81 | |||||
| 36 | 5304524452 | Pump, Drain Asmy (Replaces: 5304500535) |
|
Immediately | $ 183.11 | ||||
| 10A | 5304500432 | Screw, M8x1, 25x30, Ss, Abnt 304 |
|
$ 13.46 | |||||
| 17A | 5304500543 | Cushion, Btwn Barrier, And Motor |
|
- | |||||
| 36A | 140292102013 | Seal, Rubber, Drain Pump (Replaces: 5304500585) |
|
Immediately | $ 5.09 | ||||
| 5A | 5304500463 | Plate, Motor Support |
|
$ 86.03 | |||||
| 9A | 5304500517 | Hose, Assembly, Pressure Switch |
|
$ 54.58 | |||||
| NI | 5304500554 | Screw, Hwh M*15, Duotaptite |
|
$ 12.76 | |||||
| NI | 5304500575 | Screw, 6x20 |
|
- | |||||
| NI | 5304500823 | Harness, Washgroup (Replaces: 5304500526) |
|
$ 141.70 | |||||
| NI | 5304500556 | Screw, 1/4-10 X 28, Twinlead48 |
|
$ 11.34 | |||||
| NIA | 5304500475 | Screw |
|
- | |||||
| NIA | 5304500487 | Bracket, Tubing |
|
- | |||||
| NIA | 5304500571 | Screw, Aa Cab Torx, 5x16 Inox |
|
- |
