| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 2 | 5303305035 | Shield, Insulation |
|
- | |||||
| 2 | 5303298946 | Shield-oven Top |
|
- | |||||
| 6 | 318345216 | Rack-oven (Replaces: 5303296873) |
|
$ 103.90 | |||||
| 9 | 5303317977 | Pan,broiler |
|
- | |||||
| 10 | 5303317976 | Insert,broiler Pan |
|
- | |||||
| 12 | 5301314211 | Switch-light |
|
$ 95.29 | |||||
| 14 | 316116400 | Socket-light/lamp (Replaces: 5308011085) |
|
Immediately | $ 56.10 | ||||
| 15 | 3201908 | Lamp-oven Light |
|
- | |||||
| 16 | 5304524341 | Glass-oven Light Lens (Replaces: 3201911) |
|
Immediately | $ 14.18 | ||||
| 17 | 5304400195 | Retainer Lenz |
|
- | |||||
| 27 | 5303284616 | Clip-thermo Bulb |
|
$ 9.86 | |||||
| 41 | 5303310526 | Cover-hinge Cutout |
|
$ 83.00 | |||||
| 54 | 5303310514 | Housing-oven Light |
|
- | |||||
| 56 | 5303298951 | Trim-bodyside, Black |
|
- | |||||
| 58 | 5303299688 | Insulation, Oven Back |
|
- | |||||
| 58 | 5303304702 | Insulation, Oven Wrapper |
|
- | |||||
| 59 | 318072507 | Tube,oven Vent |
|
- | |||||
| 62 | 5304409888 | Terminal Block (Replaces: 5303310518) |
|
Immediately | $ 26.69 | ||||
| 66 | 5303322963 | Element-bake |
|
- | |||||
| 67 | 318255101 | Element, Bake (Replaces: 3202440) |
|
$ 185.70 | |||||
| 68 | 5304403015 | Support-element |
|
$ 35.04 | |||||
| 71 | 5303305037 | Shield-wire |
|
- | |||||
| 76 | 318056122 | Front-oven |
|
- | |||||
| 80 | 5303301261 | Spring,oven |
|
- | |||||
| 81 | 5303323710 | Bracket-oven |
|
- | |||||
| 83 | 318089509 | Liner-oven Assy |
|
- | |||||
| 86 | 5303310524 | Channel-hinge |
|
- | |||||
| 97 | 318066602 | Wrapper,back & Sides |
|
- | |||||
| 98 | 318029323 | Trim-side Inner Lh |
|
- | |||||
| 98 | 318029322 | Trim-side Inner Rh |
|
- | |||||
| 99 | 5303299686 | Support,adjustable |
|
- | |||||
| 101 | 318039511 | Bracket-trim |
|
- | |||||
| 103 | 318028710 | Trim-base, Black |
|
$ 129.83 | |||||
| 119 | 318003605 | Switch-thermal (Replaces: 3202388) |
|
$ 178.61 | |||||
| 121 | 318145001 | Wrapper-base |
|
- | |||||
| 127 | 318317100 | Adapter Assy (Replaces: 5303310542) |
|
$ 75.13 | |||||
| 189 | 318042500 | Retainer Plate |
|
- | |||||
| 227 | 5303323955 | Clip |
|
- | |||||
| 231 | 5303300421 | Cover-capillary |
|
- | |||||
| *24444 | 08002868 | Screw 10 X 24 X 1/2 |
|
$ 14.18 | |||||
| *24445 | 134178901 | Screw, 8 X 1/2 (Replaces: 5303211311) |
|
$ 14.89 | |||||
| *24446 | 5303319468 | Box & Wires Assy |
|
- | |||||
| *24447 | 5303324184 | Screw-8 X 5/16 |
|
Immediately | $ 14.18 | ||||
| *24448 | 5303320422 | Screw,6-20 X 5/16 ,side Trim ,(4) |
|
$ 12.71 |
