| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 58 | 3200847 | Insulation, Oven Bottom |
|
- | |||||
| 59 | 3051345 | Tube-oven Vent |
|
- | |||||
| 62 | 5304409888 | Terminal Block (Replaces: 5306563359) |
|
Immediately | $ 26.69 | ||||
| 63 | 5303212739 | Plate-ground Strap |
|
- | |||||
| 64 | 08067810 | Filter |
|
- | |||||
| 65 | 08010606 | Retainer-catalyst |
|
- | |||||
| 66 | 5303051140 | Element-broil |
|
$ 202.71 | |||||
| 67 | 316075103 | Element-bake (Replaces: 3203534) |
|
Immediately | $ 42.36 | ||||
| 68 | 3051373 | Support-element |
|
- | |||||
| 71 | 3203549 | Shield-rear Wall, Lower |
|
- | |||||
| 72 | 5303285692 | Cover-light Rod |
|
- | |||||
| 82 | 3200825 | Shield-wool Lower |
|
- | |||||
| 87 | 5303206618 | Bracket-cable Mtg |
|
- | |||||
| 90 | 3051243 | Angle-closure Rh |
|
- | |||||
| *67145 | 08067961 | Fastener-power Cord |
|
- | |||||
| *67145 | 3200846 | Fastener-edge Mtg |
|
- | |||||
| *67146 | 5303051099 | Nut, Hex, 10-32 |
|
- | |||||
| 58A | 3200833 | Insulation, Oven Wrapper |
|
- | |||||
| 58B | 3204582 | Insulation, Oven Back |
|
- | |||||
| 58C | 3131304 | Insulation, Oven Top |
|
- | |||||
| 58D | 3015337 | Insulation, Oven Vent |
|
- | |||||
| 90A | 3051242 | Angle-closure Lh (non-illustrated) |
|
- |
